Product Overview:
This system is produced by Kunshan Jierongfa Measuring and Control Equipment Co., Ltd. It measures the geometric dimensions of cable insulation and sheath based on a video measurement system. Capable of testing samples with small wire diameters, it is applied in both wire and cable production lines and laboratories. It can quickly and efficiently complete thickness, average thickness, concentricity, ovality, outer diameter, and cross-sectional area tests for insulation and sheath (single-layer annular) with one button press, thereby shortening test time and production feedback time to reduce production costs.
Measurement Range: (0.4-22) mm (customizable according to actual measurement requirements)
Ultra-high definition image for improved test accuracy;
Automatic focusing with optimal uniform light source selection;
Fast, simple, and precise automatic testing program, requiring no professional training for operation;
Manual testing is also available to meet different testing needs;
Test reports can be automatically generated;
Historical test data can be viewed at any time and exported for statistical analysis to promptly understand process capability;
Optimal sensor and weight distribution to ensure no collision or vibration occurs;
Embedded computer all-in-one unit with standardized component modules;
Can connect to external devices via network, allowing managers to view test data and monitor production status anytime and anywhere.
Dimensions (W*L*H): 580 x 450 x 840 mm
Weight: 80 kg
Supply Voltage: 100~230 V, 50~60 Hz
Input Power: ≤ 100 W
Resolution: ≦0.001mm
Sensor Type: CMOS Camera
Camera Resolution: ≦0.001mm
Light Source: LED
Number of Cameras: ~2
Measurement Error: ≦0.1%
Measurement Error: ≦5μm
Measurement Repeatability: 0.003mm
Test Time: ≤5s
Measurement Reference Standards: GB/T2951.11, IEC 60811-2
Automatic Intelligent Image Measuring System V1.0
