General Electric IS221PPDAH1B Power distribution feedback module
The GE IS221PPDAH1B is a Mark VIe Power Distribution Feedback Module (PPDA) adapted for turbine-controlled JPDM/JPDC power distribution systems. It is used for power distribution feedback signal acquisition and status monitoring, ensuring stable operation and fault early warning of industrial power systems.
Core Performance
I/O and Electrical Capabilities
Feedback Acquisition: 16-channel 24VDC status feedback input, adaptable to contact signals from circuit breakers, contactors, etc. in power distribution systems. Single-channel rated current is 2A. Supports contact closure/opening status acquisition and is compatible with 22.5-28.6VDC power supply.
Isolation and Certification: 2500Vrms isolation between channels, UL/CE certified, suitable for Class 1 Div 2 hazardous areas, vibration/shock resistant, and fault propagation prevents damage.
Diagnostic Functions: LED status indication for each channel, supports ControlST real-time diagnostics of channel status and link quality, and rapid contact fault location.
Communication and Electrical
Communication Interface: Dual 100M full-duplex Ethernet ports, supporting IONet/Modbus TCP, redundant links ensure continuous data transmission, compatible with Mark VIe distributed I/O architecture.
Power Supply: 22.5-28.6VDC, overvoltage/reverse connection protection, operating temperature -30℃ to 65℃, suitable for harsh industrial environments.
Management and Maintenance: Supports hot-swapping; failure does not affect other channels, suitable for the continuous operation requirements of turbine control.
Compatible Terminal Blocks: IS200STCIH1A/2A, IS200TBCIH2C/H4C, etc., connected via DC-37 pin connectors for flexible installation.
Email: xmxblynn@163.com
Phone: +86 18059884797
Key Technical Parameters
Parameter Value
Model IS221PPDAH1B (Mark VIe Power Distribution Feedback Module)
Compatible Systems GE Mark VIe control system, compatible with JPDM/JPDC power distribution systems
Input Channels 16 discrete contact inputs (wet contacts)
Electrical Specifications 24/28VDC, 2A per channel, 2500Vrms inter-channel isolation
Communication Dual 100M Ethernet ports, IONet/Modbus TCP
Power Supply 22.5-28.6VDC, overvoltage/reverse connection protection
Environment Class 1 Div 2, -30℃ to 65℃, vibration/shock resistant
Mounting DIN rail, hot-swappable, DC - 37-pin connector
Status In-service Mark VIe system spare part, for power distribution feedback module replacement
Typical Applications Turbine power monitoring: compatible with gas/steam turbine Mark VIe The system collects status signals from circuit breakers, contactors, and other components in the power distribution system, providing data support for power system control and fault early warning.
Process Power Monitoring: Used for power distribution status acquisition in industrial process control, suitable for power plants, petrochemical plants, and other industrial scenarios.
Equipment Power Protection: Collects power distribution status signals from equipment such as motors, pumps, and fans, providing data support for equipment protection and fault shutdown.
Spare Parts Replacement and Maintenance: Compatible with existing Mark VIe systems, used for replacing faulty power distribution feedback modules to ensure control function continuity.
