General Electric IS221PDIAH1B Full-duplex Ethernet port
The GE IS221PDIAH1B is a Mark VIe non-safety discrete input module (PDIA), adapted for turbine control and distributed I/O architectures. It features 32 discrete inputs and redundant communication, ensuring stable acquisition and real-time transmission of switch signals in industrial environments.
Core Performance:
I/O and Electrical Capabilities
Discrete Inputs: 32-channel 24VDC wet contact inputs, compatible with limit switches, pressure switches, and other contact signals. Single-channel rated current is 2A. Supports contact closure/opening status acquisition and is compatible with 22.5-28.6VDC power supply.
Isolation and Certification: 2500Vrms isolation between channels, UL/CE certified, suitable for Class 1 Div 2 hazardous areas, vibration/shock resistant, and fault propagation prevents damage.
Diagnostic Functions: LED status indication for each channel, supports ControlST real-time diagnostics of channel status and link quality, and rapid contact fault location.
Communication and Electrical
Communication Interface: Dual 100M full-duplex Ethernet ports, supporting IONet/Modbus TCP, redundant links ensure continuous data transmission, compatible with Mark VIe distributed I/O architecture.
Power Supply: 22.5-28.6VDC, overvoltage/reverse connection protection, operating temperature -30℃ to 65℃, suitable for harsh industrial environments.
Management and Maintenance: Supports hot-swapping; failure does not affect other channels, suitable for the continuous operation requirements of turbine control.
Compatible Terminal Blocks: IS200STCIH1A/2A, IS200TBCIH2C/H4C, IS400STCIH1A/2A/8A, etc., connected via DC-37 pin connectors for flexible installation.
Email: xmxblynn@163.com
Phone: +86 18059884797
Key Technical Parameters
Parameter Value
Model IS221PDIAH1B (Mark VIe Discrete Input Module)
Compatible System GE Mark VIe Control System
Input Channels 32 Discrete Contact Inputs (Wet Contact)
Electrical Specifications 24/28VDC, 2A per channel, 2500Vrms inter-channel isolation
Communication Dual 100M Ethernet ports, IONet/Modbus TCP
Power Supply 22.5-28.6VDC, overvoltage/reverse connection protection
Environment Class 1 Div 2, -30℃ to 65℃, vibration/shock resistant
Mounting DIN rail, hot-swappable, DC - 37-pin connector
Status Spare part for in-service Mark VIe systems, used for replacing discrete input modules
Typical Applications Turbine Control Monitoring: Adapts to Mark VIe systems for gas/steam turbines, acquiring switch signals such as speed, vibration, and pressure to provide status input for turbine control, valve regulation, etc.
Process Status Acquisition: Used for acquiring limit and pressure contact signals in industrial process control, suitable for power plants, petrochemical plants, and other industrial scenarios.
Equipment Status Monitoring: Acquires operating status signals from equipment such as motors, pumps, and fans, providing data support for equipment protection and fault early warning.
Spare Parts Replacement and Maintenance: Compatible with existing Mark VIe systems, used for replacing discrete input modules in case of faults, ensuring continuity of control functions.
