Main Application
This machine is widely used for granulation in the industries of pharmaceutics,chemical, solid beverage,chicken and foodstuff,etc.
Working principle
Through the transmission gear,extruding knife and pressing knife rotates in the opposite direction,pressing knife presses the wet material downward,extruding knife
pushes the wet material through the screen compulsively and the the particles form.All parts of the machine that contacts material are made of stainless steel,It is easy
to clean and maintain.This machine is suitable for the material that has viscosity.
Technical Parameters
Model | XZL-250 | XZL-300 | XZL-350 |
Production capacity (kg/batch) | 100-200 | 140-400 | 300-600 |
Motor power(kw) | 3 | 4 | 7.5 |
Rolling knife speed（rpm) | 50 | 50 | 50 |
Rolling knife diameter(mm) | 250 | 300 | 350 |
Granule diameter(mm) | Ф0.5mm-8mm | Ф0.5mm-8mm | Ф0.5mm-8mm |
Weight(kg) | 350 | 400 | 780 |
Overall dimension(mm) | 700x540x1300 | 880x640x1300 | 1300x800x1200 |
