Home > Electrical & Electronics > Passive Components > Signal Filter > Ka-Band Cavity Diplexer, 24.8–26.2 GHz, High Isolation ≥60 DB, 10W, SMA Female
Ka-Band Cavity Diplexer, 24.8–26.2 GHz, High Isolation ≥60 DB, 10W, SMA Female
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2016
Annual Export Value:
US$5 Million - US$10 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
Chengdu City
Delivery Detail:
15 days
Related Products
-
1.2GHz Notch Filter for GPS/GNSS & Radar Interference, 1166-1300MHz @ 50dB, SMA FemaleNegotiableMOQ: 1 Piece -
C-Band (3450-3550MHz) Notch Filter for 5G & Satellite Systems | 50dB Rejection, 20WNegotiableMOQ: 1 Piece
-
C-Band Notch Filter for 5G N77n78 & Satellite Coexistence 3700-3980MHz, 40dBNegotiableMOQ: 1 Piece
-
High-Power 50W Notch Filter for Cellular & Broadcast Interference, 650-800MHz @ 40dB, N-TypeNegotiableMOQ: 1 Piece
-
X-Band Notch Filter, 8400-8450MHz, 20dB Rejection, 20W, SMA-femaleNegotiableMOQ: 1 Piece
The CDU24829M26173Q05A is a high-performance RF component designed for demanding applications in satellite communications, 5G millimeter-wave systems, and radar. Operating across two precise frequency bands (24.8–25.2 GHz and 25.8–26.2 GHz) , it delivers excellent channel isolation, low insertion loss, and high power handling in a compact, rugged package. Ideal for systems requiring reliable frequency separation with minimal signal degradation.
Applications
Satellite Communication Terminals & Gateways
5G mmWave Base Stations & Repeaters
Radar & Electronic Warfare Systems
Microwave Point-to-Point Backhaul
High-Frequency RF Subsystems
