Cavity Bandpass Filter, 2170-2290MHz, Low Loss, High Rejection, IP65, N-Female
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2016
Annual Export Value:
US$5 Million - US$10 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
Chengdu City
Delivery Detail:
15 days
Related Products
-
X-Band Cavity Bandpass Filter , 9143MHz-9243MHz, High Rejection, SMA FemaleNegotiableMOQ: 1 Piece -
Ka-Band Highpass Filter 25.5GHz–27GHz, Low Insertion Loss, 2.92mm Female, 5WNegotiableMOQ: 1 Piece
-
Ka-Band Cavity Diplexer, 24.8–26.2 GHz, High Isolation ≥60 DB, 10W, SMA FemaleNegotiableMOQ: 1 Piece
-
1.2GHz Notch Filter for GPS/GNSS & Radar Interference, 1166-1300MHz @ 50dB, SMA FemaleNegotiableMOQ: 1 Piece
-
C-Band (3450-3550MHz) Notch Filter for 5G & Satellite Systems | 50dB Rejection, 20WNegotiableMOQ: 1 Piece
Concept model CBF02170M02290Q07N is a high-performance cavity bandpass filter designed for demanding RF and microwave applications in the 2170-2290MHz frequency range. Engineered with precision-machined aluminum cavity structure, this filter delivers exceptional electrical performance, high reliability, and excellent environmental resilience, making it suitable for both indoor and outdoor installations.
Primary Applications
• 5G NR Base Stations (n1, n66, n70 bands)
• LTE / 4G Cellular Infrastructure
• Satellite Communication Terminals
• Public Safety & Military Communications
• Radar & Avionics RF Front-Ends
