40-inch PP grooved filter element with surface slitting, large dirt-holding capacity, supplied by Henan Jiashuo Environmental Protection Technology Co., Ltd.
Product introduction:
PP melt-blown filter element (abbreviation: melt-blown filter element) is a tubular filter element made of polypropylene particles that are odorless and tasteless. It is produced through processes such as heating and melting, spinning, drawing, and forming. If the raw material is mainly polypropylene, it can be called a PP melt-blown filter element. It is not only widely used in water purification but also has excellent chemical compatibility, suitable for filtering strong acids, strong alkalis, and organic solvents. It has a large dirt-holding capacity, long service life, and low cost.
Product features:
Filtration efficiency and precision: The pore size and density of the PP melt-blown filter element are uniform, and the filtration efficiency reaches over ***.
Low filtration resistance, large filtration flow rate, large dirt-holding capacity, and long service life. During the production process of the PP melt-blown filter element, the fiber diameter and gap can be adjusted. The inner pores of the filter element are small while the outer pores are large, which increases the flow rate and dirt-holding capacity. The filter element is not easy to block, thus extending its service life.
High self-cleanliness, no pollution to water quality, resistant to acids, alkalis, and organic solvents, and corrosion-resistant.
High strength. When the water pressure difference between the inlet and outlet of the filter exceeds 0.4Mpa, the filter element will not deform. When the temperature exceeds 90°C, the filtration efficiency will not decrease.
After the polypropylene of this product is modified, it has extremely high hydrophilicity and can absorb ten times its own weight of water. Therefore, it can be used for oil-water separation.
Product specifications:
Length: 10 inches, 20 inches, 30 inches, 40 inches
Precision: 1, 3, 5, 10, 20, 30, 60 (μm)
Applicable pH value: 1 - 13
Pressure difference: Forward 0.4Mpa.
Operating temperature: Below 70°C at 0.25Mpa.
Sterilization: Resistant to 126°C for 30 minutes of online steam sterilization.
Endotoxin: The water extract of the filter column is tested by lAL, and the endotoxin content is less than 0.5EU/ml
Precautions:
Select the filter element according to the precision of the filtered liquid and the impurities it contains. For viscous liquids, two-stage filtration can be used. The first stage is coarse filtration to reduce resistance and extend the service life of the filter element (generally 3 - 4 times).
Install the melt-blown filter element correctly. If the filtered water is found to be polluted, carefully check whether the filter element is skewed and whether the two ends are strictly aligned and tightened.
When the pressure difference reaches 0.2MPa, the filter element should be cleaned or replaced.
Warm reminder:
All the filter elements in the filter need to be replaced regularly to ensure the filtering effect of the filter.
There may be a mismatch between the marked price and the picture in the text. Please contact me for verification before purchasing.
Order hotline: 18567552513 Henan Jiashuo Environmental Protection Technology Co., Ltd. Direct supply from the manufacturer Complete models Welcome to inquire!
