Home > Auto, Motorcycle Parts & Accessories > Auto Parts > Auto Compressor > Oriental Motor 2ik6gn-aw2j Small Induction Motor
Oriental Motor 2ik6gn-aw2j Small Induction Motor
Key Specifications
Get Latest Price
Main Markets:
North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, Eastern Asia, Western Europe, Central America, Northern Europe, Southern Europe, South Asia, Domestic Market
Location:
Zhengzhou, Henan, China
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Fujilatex Hydraulic Buffer Fwm-2725fbd-c Adjustable Shock Absorber, Pingshan TradingUS$ 90.77 - 92.31MOQ: 1 Piece -
Japan Tech-try High-precision Weight Sensor Lts-005-r-150NegotiableMOQ: 0 Piece
-
Japanese Tech-try Liquid Leak Detector Sensor Tfp-f-23.5m, Hirayama TradingNegotiableMOQ: 0 Piece
-
Vessel Fixed Pneumatic Shears gt - Nf05 With High Precision for Gate CuttingNegotiableMOQ: 0 Piece
-
Japanese Tech-try Liquid Leak Detector Sensor Kp-7-c Sold by Hirayama TradingNegotiableMOQ: 0 Piece
Oriental motor Oriental Motor 2IK6GN-AW2J Small Induction Motor
Oriental motor Oriental Motor 2IK6GN-AW2J Small Induction Motor
Oriental motor Oriental Motor 2IK6GN-AW2J Small Induction Motor
| Installation Dimensions | 60 mm |
|---|---|
| Output | 6 W |
| Series | World Standard K Series |
| Type | Wire |
| Reduction Ratio | - |
| Rated Time | Continuous |
| Rotation Direction | Varies depending on the combined reducer. |
| Voltage / Frequency / Current | Single-phase 100 V / 50 Hz / 0.199 A Single-phase 100 V / 60 Hz / 0.217 A |
| Starting Torque (Motor Shaft) | Single-phase 100 V / 50 Hz: 45 mN·m Single-phase 100 V / 60 Hz: 40 mN·m |
| Rated Torque / Rated Speed (Motor Shaft) | Single-phase 100 V / 50 Hz: 49 mN·m / 1200 r/min Single-phase 100 V / 60 Hz: 41 mN·m / 1450 r/min |
| Speed when the Reducer is Installed | Varies depending on the combined reducer. |
| Allowable Torque of the Reducer Output Shaft | Varies depending on the combined reducer. |
| Allowable Inertia J | Varies depending on the combined reducer. |
| Capacitor | Product Name: CH35FAUL2, Capacity: 3.5 µF, Rated Voltage: 250 VAC |
| Overheat Protection Device | Impedance-type Protection Device |
| Weight | 0.7 kg |
