23-seat sightseeing vehicle for Hengdian Scenic Area. Electric sightseeing vehicle with 23 seats for large scenic areas, factories, and docks
Configuration list of 23-seat enclosed electric sightseeing vehicle
Configuration system: 96 V Permanent magnet synchronous system |
||||
Electrical system |
Controller |
Permanent magnet synchronous controller |
||
Battery |
Lithium iron phosphate battery 96V 230AH |
|||
Electric motor |
Special permanent magnet synchronous motor 96V/15KW |
|||
Charger |
Intelligent charger dedicated to lithium batteries 96V/35A, charging time |
|||
DC converter |
High-power isolated DC converter 96V/12V - 500W |
|||
|
Body configuration |
Front windshield and wiper |
Automotive laminated glass, windshield wiper |
||
Roof |
Aluminum profile frame with GFRP fiberglass roof panel for lightweight design |
|||
Seat |
Ergonomic design. Luxury PU fabric seats made of cold-foamed sponge that won't deform over time |
|||
Floor |
Aluminum alloy anti-slip floor |
|||
Body |
The body is made of sheet metal, GFRP fiberglass, and aluminum profiles with lightweight design, featuring unique advantages such as beautiful appearance, durability, and light weight |
|||
Chassis |
National standard steel. The main beam is processed by patented technology of splicing and welding, pickling, phosphating, and cathodic electrophoresis for rust prevention |
|||
Rearview mirror |
One manually adjustable and foldable exterior rearview mirror on each side |
|||
LED lighting signals |
Headlights, turn signals, reverse lights, brake lights, fog lights |
|||
Instrument panel |
Molded instrument panel, electric vehicle combination meter, electric lock switch, combination switch, two-speed wiper switch, emergency double-flash switch |
|||
Steering system |
Turbine steering gear + EPS electric power assist |
|||
Braking system |
Front and rear drum brakes + hydraulic dual-circuit braking system, vacuum electronic power assist + handbrake for parking |
|||
Suspension system |
Front: Integral front axle leaf spring + damper; Rear: Integral rear axle leaf spring + damper |
|||
Audio speakers |
USB pluggable playback host, dual audio playback. Horn, reverse warning buzzer |
|||
Tires |
185/70R14C + Wheel covers |
|||
|
Technical parameters |
Length * Width * Height |
6180*1840*2150(mm) |
Curb weight |
2140 (kg) |
Rated passengers (persons) |
23 persons |
Trunk size |
--- |
|
Driving speed |
≤30km/h |
Trunk load capacity |
--- |
|
Endurance mileage (km) |
≤80 - 100 (km) |
Minimum ground clearance |
330mm |
|
Gradeability |
≥10% |
Wheelbase |
3700±10(mm) |
|
Slope parking performance |
20% |
Track width (front/rear) |
1575/1565 (mm) |
|
Minimum turning radius |
≤7.5m |
Braking distance |
≤5m |
