HST Universal Hardness Tester 250kgf Brinell, Rockwell, Vickers Hardness Machines HST-HBRV250STEW for Lab
US$ 9300 - 11060
MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Testing Machine
Accuracy Class:
High Accuracy
Accuracy:
≤± 1%
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
HST Universal Hardness Tester 1-Year Warranty Brinell, Rockwell, Vickers Hardness Machines HST-HUS-187.5 for LabUS$ 8500 - 11000MOQ: 1 Set -
HST Hot Sale High Quality Fully Automatic Six-station Vickers/Micro Hardness Tester HST-HVS-AT-XYZF-6US$ 18800 - 22200MOQ: 1 Set
-
HST Hardness Tester Test Display Type ForceTouch Screen Superficial Rockwell Hardness Tester HST-HSRS45THUS$ 1600 - 2000MOQ: 1 Set
-
HST-HRS150/45T-Z-G Automatic Rockwell and Superficial Rockwell Hardness TesterUS$ 8000 - 9500MOQ: 1 Set
-
HST-HSRS45 Touch Screen Display Superficial Rockwell Hardness Tester With LCDUS$ 10846.75MOQ: 1 Set
Accuracy Class
High Accuracy
Accuracy
≤± 1%
brand name
HST
place of origin
Shandong, China
Application
Universal Testing, Auto Testing, Plastic Testing, Textile Testing, Paper Testing, Strength Testing, Tensile Testing, Compression Testing, Impact Testing
customized support
OEM, ODM
power
/
Protection Class
IP65
Voltage
220 V, 110 V
warranty
1 Year
Product name
Universal hardness tester
Model
HST-HBRV250STEW
Hardness scale
Brucellosis, Vickers, Rockwell, Superficial Rockwell
Rockwell test force
60kgf (558.4N), 100kgf (980.7N), 150kgf (1471N)
Brinell test force
2.5kgf(24.5N)~250kgf(2450N)
Vickers test force
3kgf(29.4N)~ 250kgf(2450N)
Resolution
Rockwell: 0.1HR, Brinell: 0.1HB, Vickers: 0.1HV
Max. Height of Specimen
Rockwell: 230mm, Brinell & Vickers: 160mm
Throat
170mm
Power supply
AC110-220V,50Hz
HST-HBRV250STEW Universal hardness tester 250kgf
For price and model details, please contact Lisa:
Email:lisa@hssdtest.com Whatsapp/Wechat: 008615866783008
Products Description
1.Product Introduction :
It has Brinell, Rockwell and Vickers three test modes and test forces from 3kg to 250kg, which can test several kinds of hardness.
Test force loading, dwell, unload adopts automatic shifting for easy and fast operation. It can show and set the present scale, test force, test indenter, dwell time and hardness conversion;
The main function is as follows: Selection of Brinell, Rockwell and Vickers three test modes; Conversion scales of different kinds of hardness; Test results can be saved for checking or be printed out, automatic calculation of maximum, minimum and average value; can connect to the computer.
Suitable for hardened and surface hardened steel, hard alloy steel, casting parts, non-ferrous metals, various kinds of hardening and tempering steel and tempered steel, carburized steel sheet, soft metals, surface heat treating and chemical treating materials etc.
Model HST-HBRV250STE is used electronic loading control instead of weight load control, equipped with a newly-designed large displaying screen with good reliability, excellent operation and easy watching, thus it is a high-tech product combining the optic, mechanic and electric features.
It has Brinell, Rockwell and Vickers three test modes and test forces from 3kg to 250kg, which can test several kinds of hardness.
Test force loading, dwell, unload adopts automatic shifting for easy and fast operation. It can show and set the present scale, test force, test indenter, dwell time and hardness conversion;
The main function is as follows: Selection of Brinell, Rockwell and Vickers three test modes; Conversion scales of different kinds of hardness; Test results can be saved for checking or be printed out, automatic calculation of maximum, minimum and average value; can connect to the computer.
2.ApplicationRange
Suitable for hardened and surface hardened steel, hard alloy steel, casting parts, non-ferrous metals, various kinds of hardening and tempering steel and tempered steel, carburized steel sheet, soft metals, surface heat treating and chemical treating materials etc.
3.Specifications
Model |
HST-HBRV250STEW |
Rockwell Test Force |
60kgf (558.4N), 100kgf (980.7N), 150kgf (1471N) |
Superficial Test Force |
15kgf(147.11N),30kgf(294.2N),45kgf(441.3kgf) |
Brinell Test Force |
2.5kgf(24.5),5kgf(49N),6.25kgf(61.25N),10kgf(98N),15.625kgf(153.125N),30kgf(294N),31.25kgf(306.25N),62.5kgf(612.5N)100kgf(980N), 125kgf(1225N), 187.5kgf(1837.5N), 250kgf(2450N) |
Vickers Test Force |
3kgf(29.4N)5kgf(49N),10kgf(98N),20kgf(196N),30kgf(294N),50kgf(490N), 100kgf(980N), 200kgf(1960N),250kgf(2450N) |
Indenter |
Diamond Rockwell Indenter, Diamond Vickers Indenter, ф1.588mm, ф2.5mm, ф5mm Ball Indenter |
Loading Method |
Automatic (Loading/Dwell/Unloading) |
Hardness Reading |
Touch Screen Display |
Test Scale |
HRA, HRB, HRC, HRD, HBW1/30, HBW2.5/31.25, HBW2.5/62.5, HBW2.5/187.5, HBW5/62.5, HBW10/100, HV30, HV100 |
Conversion Scale |
HV, HK, HRA, HRB, HRC, HRD, HRE, HRF, HRG, HRK, HR15N, HR30N, HR45N, HR15T, HR30T, HR45T, HS, HBW |
Lense magnification |
Eyepiece:15X, Objective:2.5X(Brinell),5X(vickers),optional 10X,20X |
Magnification |
Brinell: 37.5×, Vickers: 75×, optional :150X,300X |
Resolution |
Rockwell: 0.1HR, Brinell: 0.1HB, Vickers: 0.1HV |
Dwell Time |
0~60s |
Data Output |
Printer |
Max. Height of Specimen |
Rockwell: 230mm, Brinell & Vickers: 160mm |
Throat |
170mm |
Power Supply |
AC110-220V，50Hz |
Execute Standard |
ISO 6508，ASTM E-18，JIS Z2245，GB/T 230.2 ISO 6506，ASTM E10-12，JIS Z2243，GB/T 231.2 ISO 6507，ASTM E92，JIS Z2244，GB/T 4340.2 |
Dimension |
475×200×700mm，Packing Dimension: 620×420×890mm |
Weight |
Net Weight: 64kg，Gross Weight: 92kg |
Detailed Photos:
Digital eyepiece (for Vickers, Brinell hardness test) Built-in cold light source (for Vickers hardness test)
External ring lamp (for Brinell hardness test) Slipped test table, frictionless screw
