Help CenterSupply of Anti-corrosion Aluminum Anodes for Ballast Water Tanks, Manufacturer of Aluminum Alloy Sacrificial Anodes
Related Products
-
National Standard Magnesium Anodes for Tank Anti - Corrosion, 14kg Buried Magnesium AnodesUS$ 3.38MOQ: 1 Piece -
Cathodic Protection Magnesium Anode Sacrificial Anode, 22kg Magnesium AnodeUS$ 0.46MOQ: 10 Pieces
-
Shandong Dongying Aluminum-zinc-indium-magnesium-titanium Sacrificial AnodesUS$ 3.54MOQ: 1 Piece
-
Zinc Alloy Anodes for Ballast Tanks, Flat Iron Zinc Sacrificial Anodes, 5kgUS$ 2.77MOQ: 1 Piece
-
High-efficiency Aluminum Anode, High-temperature Resistant Aluminum Alloy Sacrificial Anode, 23kg Aluminum Block ManufacturerUS$ 2.92 - 3.08MOQ: 3 Pieces
Supply anti-corrosion AI-1 aluminum anode for ballast water tanks Manufacturer of aluminum alloy sacrificial anodes
Highly activated aluminum alloy anode 1.45-1.50 1.40-1.45 ≥2080 ≥70
Against the backdrop of participating in the large-scale development of the western region, Jiaozuo Libo Light Alloy Co., Ltd. takes "sincerity, dedication, and innovation" as new opportunities to establish an industrialization base integrating production, learning, and research. Centering around the anti-corrosion cause, guided by the three markets of pipelines, oil fields, and wharves, with sales as the leader, an authoritative quality inspection platform and technical consultation as the core, an efficient management system as the guarantee, and human resources as the foundation, the company integrates development resources, focuses on continuously promoting the in-depth development of 9 high-tech technologies, cultivates a first-class team, creates first-class products, and makes greater contributions to the anti-corrosion cause in China and even the world with first-class services!
Company Profile
Jiaozuo Libo Light Alloy Co., Ltd. is located in Wuzhi, Jiaozuo, Henan Province in the Central Plains region. It is a new-type enterprise specializing in the production, sales, scheme design, engineering construction, and technical consultation of cathodic protection materials. The company strengthens internal management and operates in a standardized manner, and has passed the ISO9001 international quality certification and won honors such as "China's Demonstration Enterprise with Double Guarantees of Quality and Reputation" and "Most Influential Brand in the Anti-corrosion Industry".
The company's main products include: magnesium alloy sacrificial anodes, aluminum alloy sacrificial anodes, zinc alloy sacrificial anodes, magnesium strips, zinc strips, pre-packaged high-silicon cast iron anodes, precious metal oxide anodes, deep well anodes, insulating joints/flanges, heat-shrinkable tapes/sleeves, potentiostats, test piles, reference electrodes, thermite welding fluxes, and supporting products for cathodic protection, as well as magnesium alloy rods and deep-processed magnesium alloy products in hundreds of specifications.
Model |
Specification/mm |
Weight/kg |
A×(B1+B2)×C |
||
AC-1 |
750×(115+135)×130 |
35.0 |
AC-2 |
500×(115+135)×130 |
23.0 |
AC-3 |
500×(105+135)×100 |
16.0 |
AC-4 |
300×(105+135)×100 |
10.0 |
2. Aluminum anodes for Hong Kong-style facilities and marine engineering facilities
Model |
Specification/mm |
Weight/kg |
A×(B1+B2)×C |
||
AI-1 ×（220+240）×230 |
310.0 |
|
AI-2 |
1600×（200+210）×220 |
190.0 |
AI-3 |
1500×（170+200）×180 |
130.0 |
AI-4 |
900×（150+170）×160 |
58.0 |
AI-5 |
1500×（148+178）×170 |
120.0 |
AI-6 |
850×（180+220）×180 |
85.0 |
AI-7 |
800×（200+280）×150 |
80.0 |
AI-8 |
700×（160+220）×180 |
72.5 |
AI-9 |
1250×（115+135）×130 |
56.0 |
AI-10 |
1000×（115+135）×130 |
46.0 |
AI-11 |
750×（115+135）×130 |
35.0 |
AI-12 |
500×（115+135）×130 |
23.0 |
Protection effect detection
According to the anode structure, each sacrificial anode has two welding feet and four welds. It is required that the length of each weld is greater than 80mm, the weld height is 5 - 7mm. The welds should be continuous, flat, without false welding, firmly welded, and should not fall off for 30 years, and have good electrical connection with the steel pipe pile.
Aluminum alloy sacrificial anodes have extremely high electrochemical performance. The power generation of anode materials per unit weight is large, about three times that of zinc anodes and twice that of magnesium anodes. In seawater and other media containing chloride ions, they have good performance and strong self - regulating ability of the emitted current.
Aluminum alloy sacrificial anodes are suitable for the cathodic protection of metal anti - corrosion of ships, mechanical equipment, marine engineering and port facilities in seawater media, as well as pipelines and cables in sea mud.
Aluminum alloy sacrificial anodes have good self - solubility, high current efficiency, and good self - regulating performance of the anode current. They are suitable for the cathodic protection of metal anti - corrosion of ships, mechanical equipment, marine engineering and port facilities in seawater and fresh water media, as well as pipelines and cables in low - resistivity soil.
The electrochemical properties of three Al-Zn-In series alloy anodes were measured by the constant current method. The metallographic structures of the three anode materials were analyzed by metallographic microscope and scanning electron microscopy (SEM). The results show that: the smaller the anode grain size, the higher the current efficiency; the fewer the number of the second phase in the anode, the higher the current efficiency, but the dissolution is uneven; the current efficiency and dissolution uniformity of the anode are related to the preferential dissolution and shedding of the second phase.
