Home > Construction & Decoration > HVAC System & Parts > Singlephase Constant Wattage Heating Cable Two Core Parallel Constant Wattage Heating Cable
Singlephase Constant Wattage Heating Cable Two Core Parallel Constant Wattage Heating Cable
US$ 2 - 5
MOQ: 10 Meters
Key Specifications
Get Latest Price
Warranty:
2 Years
Floor Heating Valve:
All available
After-sale Service:
Online Technical Support, Return and Replacement
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Pfa Constant Wattage Heating Cable Heating Cable Coil at Constant Power 30w230vUS$ 2 - 5MOQ: 10 Meters -
Fep Insulated Constant Power Heating Cable Constant Wattage Heating Mat Cable Constant Power Heater Cable WireUS$ 2 - 5MOQ: 10 Meters
-
Twophase 380v Parallel Constant Power Heating Cable Single Phase Constant Wattage Heat Trace Cable for Oil and GasUS$ 2 - 5MOQ: 10 Meters
-
230V 25W/M Parallel Constant Power Heating Cable and WireUS$ 2 - 5MOQ: 10 Meters
-
Quality 230v 30w 40w Pipe Heating 12 Volt Heating Cable Electric Under Floor Heating SystemUS$ 2 - 5MOQ: 10 Meters
Warranty
2 Years
Floor Heating Valve
All available
After-sale Service
Online Technical Support, Return and Replacement
Material
Polyolefin/FEP/PVC, FEP
Project Solution Capability
graphic design, 3D model design, Others
Application
Hotel, Pipe heating trace / roof & gutter de-icing
Design Style
Modern
Place of Origin
Anhui, China
Brand Name
youyu
Model Number
customized
Type
Floor Heating Parts
Floor Heating Part Type
Floor Heating Cables
Conductor Material
Copper
Number of Conductor
2~3
Rated Voltage
230V
Bending radius
38mm
Conductor insulation
FEP
Outer Insulation
FEP
Min. Installation Temp.
-20℃
Output
20~60w/ft(28w/m)+-10%
Product Description
Constant Wattage Heating Cable is divided into parallel type and series type, Parallel constant wattage heating cable is connected by multiple heating nodes in parallel across the entire length. It can be shared to use according to actual length, but at least reserve one heating node. Series type is suitable for the case where the circuit length exceeds the upper limit of the parallel constant wattage cable.
Two paralleled stranded copper wire as the bus wires with insulation layer FEP, then wrap the nickel-chromium alloy as the heating wire connect with bus wires at regular intervals, form the parallel resistance. Finally covered with insulation jacket FEP. When the bus wires power on, each parallel resistance begin to heat, thus form a continuous heating cable.
Technical Data Sheet of Two-core Parallel Type Constant Wattage Heating Cable (220V) |
||||||||||
Two-core Parallel Type |
Rated
Voltage
(V)
|
Rated
Power
(w/m)
|
Max Application
Length(m)
|
Max Maintain Temperatue of Fluid (℃) |
Max Tolerance Temperature(℃) |
|||||
RDY2Q-J3-10 |
220 |
10 |
200 |
150 |
205 |
|||||
RDY2Q-J3-20 |
220 |
20 |
120 |
140 |
205 |
|||||
RDY2Q-J3-30 |
220 |
30 |
100 |
125 |
205 |
|||||
RDY2Q-J3-40 |
220 |
40 |
100 |
100 |
205 |
|||||
Technical Data Sheet of Two-core Parallel Type Constant Wattage Heating Cable (380V) |
||||||||||
Two-core Parallel Type |
Rated
Voltage
(V)
|
Rated
Power
(w/m)
|
Max Application
Length(m)
|
Max Maintain Temperatue of Fluid (℃) |
Max Tolerance Temperature(℃) |
|||||
RDY2Q-J3-20-380 |
380 |
20 |
300 |
130 |
205 |
|||||
RDY2Q-J3-30-380 |
380 |
30 |
230 |
125 |
205 |
|||||
RDY2Q-J3-40-380 |
380 |
40 |
185 |
100 |
205 |
|||||
Technical Data Sheet of Three-core Parallel Type Constant Wattage Heating Cable (380V) |
||||||||||
Three-core Parallel Type |
Rated
Voltage
(V)
|
Rated
Power
(w/m)
|
Max Application
Length(m)
|
Max Maintain Temperatue of Fluid (℃) |
Max Tolerance Temperature(℃) |
|||||
RDY3Q-J3-20 |
380 |
20 |
390 |
150 |
205 |
|||||
RDY3Q-J3-30 |
380 |
30 |
320 |
140 |
205 |
|||||
RDY3Q-J3-40 |
380 |
40 |
300 |
130 |
205 |
|||||
RDY3Q-J3-50 |
380 |
50 |
250 |
120 |
205 |
|||||
Technical Data Sheet of Two-core Parallel Type Constant Wattage Heating Cable (220/380V) |
||||||||||
Two-core Parallel Type |
Rated
Voltage
(V)
|
Rated
Power
(w/m)
|
Max Application
Length(m)
|
Max Maintain Temperatue of Fluid (℃) |
Max Tolerance Temperature(℃) |
|||||
RDY2Q-J4-40 |
220/380 |
40 |
120 |
200 |
260 |
|||||
RDY2Q-J4-50 |
220/380 |
50 |
110 |
180 |
260 |
|||||
RDY2Q-J4-60 |
220/380 |
60 |
100 |
160 |
260 |
|||||
Parallel constant wattage heating cable can be used for pipe and equipment freeze protection and process temperature maintenance requiring high power output or high temperature exposure. This type provide an economical alternative to self regulating heating cable but requires more skill for installation and more advanced control and monitor system. Constant wattage heating cables can provide process temperature maintenance up to 150°C and can withstand exposure temperatures up to 205°C with power on.
