Home > Electrical & Electronics > Electrical Control System > PIONEER MAGNETICS PM1253AL-6-3-Z03 Power Module

PIONEER MAGNETICS PM1253AL-6-3-Z03 Power Module

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Material:

Other, Global universal model

Condition:

Other, Global universal model

Task:

Other, Global universal model

Contact Supplier Request Quote Chat Now

Guizhou Yuanmiao Automation Equipment Co., Ltd.

1Yr

Payment & Shipping

Payment Methods:

Port of Shipment:

guizhou

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Material Other, Global universal model

Condition Other, Global universal model

Task Other, Global universal model

Mathematical Model Other, Global universal model

Signal Other, Global universal model

Customized Non-Customized

Structure Other, Global universal model

Operating Temperature -40℃~+70℃

Relative Humidity 5%-95% (non-condensing)

Dimensions 100mm×60mm×30mm

The PIONEER MAGNETICS PM1253AL-6-3-Z03 is a power supply module. Boasting core features such as -40℃ low-temperature startup capability, UL Class I Division 2 hazardous location certification, 300% power boost function, and 92% high conversion efficiency, this module is widely used in fields with stringent requirements for power supply stability and environmental adaptability, including petrochemicals, mining, metallurgical smelting, and outdoor communication base stations. It provides continuous and reliable DC power supply for critical on-site devices such as controllers, sensors, and actuators. With a Mean Time Between Failures (MTBF) of over 500,000 hours, it ensures long-term continuous operation, serving as a core component for safeguarding power supply security in harsh industrial environments.

I. Technical Parameters

Core Output and Input Parameters
Adopting a wide-range AC input design, it is compatible with an input voltage range of 100-240V AC and supports 50/60Hz power frequency input, with an input power factor ≥0.95 (under full-load conditions). The output specification is a stable 6V DC output, with a rated output current of 3A and a rated output power of 18W. It features a 300% power boost capability, enabling a short-term (≤10ms) peak output power of up to 54W, which is suitable for short-term high-current load scenarios such as motor startup and solenoid valve actuation. The output voltage regulation accuracy is ±1%, and the load regulation rate is ≤0.5%, effectively ensuring the power supply stability of sensitive electronic equipment.
Structural and Hardware Parameters
Encapsulated in a compact metal housing made of corrosion-resistant aluminum alloy with anodized surface treatment, it achieves an IP65 protection rating, capable of resisting dust ingress and low-pressure water jets. The module dimensions are 100mm×60mm×30mm (L×W×H), supporting both DIN rail mounting and panel mounting methods, suitable for dense deployment in industrial control cabinets. Equipped with LED status indicators, it displays the power supply operating status (normal/fault) and load level in real time, facilitating quick on-site inspections.
Environmental and Reliability Parameters
It has excellent wide-temperature operating capability, with an operating temperature range of -40℃~+70℃, supporting direct startup at -40℃ without preheating devices. The storage temperature range is -55℃~+85℃, suitable for extreme climate environments such as high-latitude regions and cold areas. The relative humidity adaptation range is 5%~95% (non-condensing), allowing stable operation in humid and hot mines, coastal high-salt fog environments, etc. The Mean Time Between Failures (MTBF) is ≥500,000 hours, meeting the calculation requirements of the MIL-HDBK-217F standard and supporting 24/7 continuous operation.
Efficiency and Electromagnetic Compatibility Parameters
The power conversion efficiency is as high as 92% (under full-load conditions), and the efficiency remains above 88% under light load (50% load), effectively reducing energy consumption and heat dissipation pressure. The electromagnetic compatibility performance complies with the EN 55032 Class B standard, featuring low electromagnetic radiation and strong anti-interference capability. It can resist electromagnetic interference from strong interference sources such as frequency converters and motors in industrial sites, ensuring the stable operation of itself and surrounding equipment.

II. Functional Features

Wide-Range Environmental Adaptability, No Pressure in Extreme Scenarios
The core highlight of the module is its -40℃ low-temperature startup capability. It can be directly put into use in scenarios such as outdoor cold regions and polar scientific research equipment without additional heating devices, improving environmental adaptability by 50% compared with ordinary industrial power supplies (which usually only support startup at -20℃). The UL Class I Division 2 hazardous location certification allows it to be directly deployed in scenarios with flammable and explosive gases such as petrochemical tank farms and gas processing stations, eliminating the need for additional explosion-proof enclosures and reducing system integration costs. With an IP65 protection rating and corrosion-resistant housing design, its service life in high-dust underground mines and coastal high-salt fog environments can be more than 3 times that of ordinary power supplies.
300% Power Boost, Strong Dynamic Load Adaptability
It has a short-term 300% power boost function. In short-term high-current load scenarios such as motor startup and solenoid valve engagement, it can instantaneously output 54W power, avoiding equipment shutdown caused by overload protection triggering in traditional power supplies. This function performs outstandingly in the rolling mill control system of metallurgical workshops. When the module supplies power to hydraulic solenoid valves, it successfully copes with the 3-times rated current impact during solenoid valve actuation, increasing the equipment startup success rate to 100% compared with traditional power supply solutions.
High Reliability and Energy Efficiency, Optimal Operation and Maintenance Costs
The 92% high conversion efficiency significantly reduces energy consumption and heat generation during power supply operation. In large-scale factory scenarios with multi-module cluster deployment, annual power savings can be more than 30% compared with traditional low-efficiency power supplies. An MTBF of 500,000 hours means a theoretical fault-free operation time of more than 57 years. Combined with a comprehensive multi-protection mechanism, it significantly reduces the frequency of on-site operation and maintenance and the cost of spare parts replacement. In a large-scale mining project, this module has operated continuously for 3 years without faults, reducing operation and maintenance costs by 60% compared with the ordinary power supplies used previously.
Flexible Installation and Visual Monitoring, Convenient Deployment and Maintenance
It supports both DIN rail and panel mounting methods. The compact size design enables dense deployment in narrow control cabinets, increasing the number of units installed per cabinet by 40% compared with ordinary power supplies of the same power rating. The front-end LED indicators clearly distinguish operating statuses such as "power normal", "overload", and "overtemperature". Operation and maintenance personnel can quickly judge the power supply operating status through visual inspections, shortening fault identification time to within 1 minute. The module has a built-in fault self-recovery function, which can automatically resume power supply after non-permanent faults such as instantaneous overload and overvoltage are eliminated, reducing the need for manual intervention.

III. Working Principle and Applications

3.1 Working Principle

The PM1253AL-6-3-Z03 achieves reliable power supply based on the core logic of "wide-range rectification - high-efficiency conversion - stable output - intelligent protection". The specific process is as follows:

① Input Rectification Stage: The 100-240V AC wide-range input is converted into high-voltage DC through a bridge rectifier circuit, and high-frequency interference in the power grid is filtered out by an EMC filter module to ensure pure input power.

② Power Conversion Stage: The high-voltage DC is converted into a high-frequency AC signal through a PWM (Pulse Width Modulation) circuit, and voltage step-down is performed through a high-frequency transformer. This stage adopts a high-efficiency topology to achieve a 92% conversion efficiency.

③ Output Voltage Stabilization Stage: The high-frequency low-voltage AC signal is converted into 6V DC voltage through secondary rectification and filtering. The PWM duty cycle is adjusted in real time through a voltage feedback loop to ensure an output voltage accuracy of ±1%.

④ Power Boost Stage: When the load current is detected to exceed the rated value, the power boost module is automatically activated, and 300% short-term power output is achieved through supercapacitor energy storage and release.

⑤ Protection and Monitoring Stage: The output current, voltage, and module temperature are monitored in real time. When overcurrent, overvoltage, overtemperature, or short circuit occurs, the protection mechanism is triggered immediately to cut off the output, and an alarm is issued through the LED indicator at the same time. After the fault is eliminated, it will automatically recover or remain locked according to the fault type.

3.2 Application Scenarios

Petrochemical Tank Farm Power Supply System: In the tank farm monitoring system of a large petrochemical enterprise, the module is deployed in an on-site explosion-proof control cabinet to provide 6V DC power supply for tank farm liquid level sensors, combustible gas detectors, and remote I/O modules. The UL Class I Division 2 certification ensures its safe operation in flammable and explosive environments. The -40℃ low-temperature startup capability meets the outdoor installation requirements in northern winter. The 300% power boost function ensures short-term high-current power supply during emergency valve closing of solenoid valves, with a 2-year fault-free operation record.
Underground Mine Monitoring Equipment Power Supply: In the monitoring system of a coal mine heading face, the module supplies power to gas sensors, personnel positioning card readers, and other equipment. The IP65 protection rating resists dust and water spray intrusion underground. The wide-temperature operating range adapts to the temperature fluctuation of -10℃~+40℃ underground. The 2500V AC electrical isolation capability effectively avoids the interference of underground stray current on sensors, ensuring accurate and reliable gas concentration data collection.
Outdoor Communication Base Station Power Supply in Cold Regions: In outdoor communication base stations in cold regions of Northeast China, the module serves as the core conversion unit of the backup power supply, converting the base station main power supply into 6V DC to power base station monitoring modules and emergency lighting equipment. The -40℃ low-temperature startup capability ensures the normal startup of the base station in extreme low-temperature weather in winter. The 92% high conversion efficiency reduces base station energy consumption. The 500,000-hour MTBF ensures the reliability of long-term unattended operation of the base station.
Metallurgical Workshop Equipment Power Supply: In the hot rolling workshop control system of an iron and steel enterprise, the module provides stable 6V DC power supply for temperature sensors and pressure transmitters in the workshop. The module's strong anti-interference capability resists electromagnetic noise generated by frequency converters and motors in the workshop. The overtemperature protection function adapts to the high-temperature environment above 40℃ in the workshop. The 300% power boost function ensures the power supply stability during equipment startup and shutdown, effectively reducing production interruptions caused by power supply fluctuations.

IV. Common Faults and Troubleshooting Methods

Fault 1: Module Fails to Start, No Output Voltage
Possible Causes: Input voltage exceeds the range; poor contact or disconnection of the input line; insufficient startup current in low-temperature environments; failure of the internal startup circuit of the module.
Troubleshooting Methods:
① Measure the input voltage with a multimeter to ensure it is within the range of 100-240V AC. If the fluctuation is large, a voltage stabilizer should be installed.
② Check the tightness of the input terminal block, re-plug and unplug the wiring, clean the oxide layer on the terminals, and test the line continuity with a multimeter.
③ When starting in an extreme low-temperature environment below -40℃, the module can be preheated for 30 minutes (e.g., placed close to heating equipment) before startup.
④ If the above measures are ineffective, replace it with a spare module and send the faulty module back to the factory for startup circuit maintenance.
Fault 2: Unstable Output Voltage, Fluctuation Exceeds ±1%
Possible Causes: Excessive fluctuation of input voltage; load exceeds the rated range; poor contact of the output line; failure of the module voltage feedback loop.
Troubleshooting Methods:
① Measure the input voltage fluctuation value. If it exceeds ±10%, an AC voltage stabilizer should be installed.
② Check the total load power to ensure it does not exceed the rated power of 18W, and the short-term peak power does not exceed 54W. If it exceeds, shunt the load or upgrade the module specification.
③ Check the output terminal block, re-tighten to ensure good contact, and replace aged or damaged output cables.
④ If the voltage still fluctuates, calibrate the voltage feedback loop with special equipment or contact the manufacturer for professional calibration.
Fault 3: Protection Mechanism Triggered, LED Displays Fault Alarm
Possible Causes: Load short circuit; output overload (exceeding 300% peak power); module operating temperature exceeding 70℃; abnormally high input voltage.
Troubleshooting Methods:
① Disconnect the output load, measure the load circuit resistance with a multimeter to confirm whether there is a short circuit, and power on again after eliminating the short circuit fault.
② Check the load power. If it is overloaded for a long time, increase the number of modules or replace it with a higher power model.
③ Check the module heat dissipation space to ensure the installation spacing is ≥5cm. If the ambient temperature is too high, add a cooling fan or optimize the installation position.
④ Measure the input voltage. If it exceeds 240V AC, install a voltage stabilizer. The module can automatically resume power supply after the fault is eliminated.
Fault 4: Shuts Down Immediately After Startup in Low-Temperature Environment
Possible Causes: Startup at ultra-low temperature below -40℃; excessive load during startup; failure of the module low-temperature startup auxiliary circuit.
Troubleshooting Methods:
① Build a temporary insulation shed or use a heating tape to preheat the module to above -35℃ before startup.
② Disconnect some non-critical loads during startup, and gradually connect all loads after the module runs stably.
③ If it still shuts down frequently after preheating, check the low-temperature startup auxiliary circuit and replace components such as auxiliary capacitors if necessary.
