GE IS200AEPAH1BKE IS215WEPAH2BB Analog Input/output Module

GE IS200AEPAH1BKE is an industrial-grade high-performance analog input/output module, serving as a core component of the GE Mark VI series control system. Its core function is to accurately collect, condition and output analog signals from industrial sites, capable of processing various physical quantity signals such as pressure, vibration and temperature. It realizes reliable data transmission through signal scaling and filtering, supports Triple Modular Redundancy (TMR) architecture, and is adapted to the control systems of prime movers such as gas turbines and steam turbines. Complying with industrial safety and EMC standards, it is a core signal processing unit for parameter monitoring and control of key equipment.

Operating Voltage Adapting to system power supply, typical operating voltage 24VDC

Input Signal Types Supporting LVDT input, thermocouple input, vibration input, 4-20mA current input, ±10VDC voltage input

Output Signal Types 4-20mA current output, configurable to 200mA output range via jumpers

Measurement Range 0-10bar for pressure measurement

Measurement Accuracy 0.1%FS (full scale)

Response Time Signal processing response time ≤20ms

Filter Function Built-in RC filter network, common mode rejection ratio ≥80dB

Protection Functions Built-in overvoltage protection, electromagnetic interference suppression protection

Power Consumption Typical power consumption ≤8W

Certification Standards Compliant with SIL 2/SIL 3 safety level certification, compatible with CE, UL standards

Overall Dimensions 22.5mm×60mm×101.5mm, board-type design suitable for system rack

Weight Approximately 170g, lightweight facilitating installation and deployment

Mounting Method Rack slot mounting, adapting to I/O core R1, R2, R3 installation positions

Housing Material Industrial-grade stainless steel shell with corrosion resistance

Connection Method 19 multi-spec plug connectors, including two-pin, three-pin, six-pin and other pin types

Protection Rating IP67, dustproof and waterproof, suitable for harsh industrial on-site environments

Status Indication No independent LED indicators, fault monitoring via system-associated diagnosis

Operating Temperature -40℃ to 125℃, no performance derating over the entire temperature range

Storage Temperature -40℃ to 85℃, meeting extreme storage and transportation requirements

Relative Humidity 5% to 95% (non-condensing), adapting to high-humidity industrial scenarios

Vibration Resistance Compliant with industrial equipment vibration standards, withstanding unit operation vibration environment

EMC Compliance With high anti-electromagnetic interference capability, adapting to industrial strong electromagnetic environment

Precise signal processing, 0.1%FS measurement accuracy ensuring reliable parameter monitoring

Wide signal compatibility, adapting to multiple types of analog input and output signals, reducing module selection quantity

Strong anti-interference capability, RC filter network and high common mode rejection ratio design ensuring stable signal transmission

Good redundancy adaptability, supporting TMR architecture integration to meet high availability system requirements

Strong environmental adaptability, wide temperature operating range and IP67 protection, tolerating harsh industrial conditions

High operational stability, industrial-grade materials and strict quality control, adapting to long-term continuous operation scenarios

Convenient system integration, multi-spec connector design compatible with core rack signal transmission requirements

High cost-effectiveness, achieving cost control while ensuring performance, adapting to economical project needs

• Power Industry (Gas Turbine, Steam Turbine Control)

• Oil and Gas Industry (Compressor Monitoring and Control)

• Chemical Industry (Reaction Equipment Parameter Monitoring)

• Metallurgical Industry (Power Equipment Signal Processing)

• Manufacturing Industry (Pump, Air Compressor Monitoring)

• Energy Industry (Generator Set Auxiliary System Control)
