Flexible Slope Reinforcing Mesh Intercept Rockfall Protection Wire Mesh
US$ 5.60
1 - 9999 Meter
US$ 5.40
≥10000 Meter
Key Specifications
Get Latest Price
Material:
High-tensile Steel Wire
Type:
Weave Wire Mesh
Technique:
Woven
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Chain Link Steel Net for Protection Against Rock SlideUS$ 5.40 - 5.60MOQ: 1 Meter -
Reinforced Hexagonal Wire Mesh for Rockfall and Slope Protection SystemsUS$ 3.00 - 3.10MOQ: 2000 Meters
-
Wholesale Hr30 Rockfall Protection Mesh Reinforced Hexagonal Netting for Slope Protection and RockfallUS$ 2.5 - 11.2MOQ: 1 Meter
-
Double Twisted Hexagonal Woven Mesh for Slope Stabilization & Rockfall Protection Plain Weave Cut-to-Order for SaleUS$ 2.5 - 11.2MOQ: 1 Meter
-
Rhomboid High-tensile Wire Mesh SNS Flexible Slope Stability System Rockfall Protection FenceUS$ 7.80 - 8.00MOQ: 3000 Square Meters
Technique
Woven
Model Number
645/2,65/3,65/4,80/3,80/4,80/4.6
Brand Name
LONGEN
Place of Origin
Hebei, China
Delivery Time
8-14 days
Processing Service
Bending, Welding, Decoiling, Cutting, Punching
Weave Style
Chain link
Product name
high tensile steel mesh
Diameter
2.0mm,3.0mm,4.0mm,4.6mm
Mesh size
48mm,63mm,65mm,80mm
Tensile tensile strength
>1770Mpa
Wire Material
High-tensile steel wire
Compound protection
Zn/AI coating of steel wires
Compound of corrosion protection
95% Zn / 5% AI
coating
150g/㎡
Mesh edges
Mesh ebds knotted
Flexible slope Reinforcing mesh intercept rockfall protection wire mesh
Our mesh systems are used for geohazard mitigation, specifically to prevent and manage the risks associated with rockfalls and debris flows. They act as barriers to intercept and contain falling rocks, reducing the potential impact on structures and people. Rockfall mesh is crucial in safeguarding projects and mitigating the risks posed by geological hazards.
Slope Protection Wire Mesh are engineered with high-quality materials that are built to withstand the forces of nature. These systems are designed to be long-lasting, ensuring durable protection against rockfalls over an extended period. This reliability reduces the need for frequent maintenance and replacement, saving you time and money in the long run.
Our factory can provide various specifications of slope protection wire mesh products.
-For details, please contact us
Product Description
Specification
Technical Data Sheet
CE European Technical Approval ETA-17/0118
Steel wire mesh |
||||||
Technical data |
45/2 |
65/3 |
65/4 |
|||
Wire diameter |
2.0mm |
3.0mm |
4.0mm |
|||
Steel quality |
Steel quality |
|||||
Mesh shape |
Rhomboid |
|||||
Tensile strength of steel wire |
＞1770 N/mm² |
＞1770 N/mm² |
＞1770 N/mm² |
|||
Tensile strength steel wire mesh |
min.85kN/m |
min.150kN/m |
min.150kN/m |
|||
Diagonal |
62×95mm（+/-3%） |
83×143mm（+/-3%） |
83×138mm（+/-3%） |
|||
Mesh width |
48mm |
65mm |
63mm |
|||
Compound protection |
Zn/AI coating of steel wires |
|||||
Compound of corrosion protection |
95% Zn / 5% AI |
|||||
Coating |
min.125g/㎡ |
min.150g/㎡ |
min.150g/㎡ |
|||
Mesh edges |
Mesh ebds knotted |
|||||
Technical data |
80/3 |
80/4 |
80/4.6 |
||
Wire diameter |
3.0mm |
4.0mm |
4.6mm |
||
Steel quality |
Steel quality |
||||
Mesh shape |
Rhomboid |
||||
Tensile strength of steel wire |
＞1770 N/mm² |
＞1770 N/mm² |
＞1770 N/mm² |
||
Tensile strength steel wire mesh |
102×177mm（+/-3%） |
102×177mm（+/-3%） |
102×173mm（+/-3%） |
||
Mesh width |
80mm |
80mm |
80mm |
||
Compound protection |
Zn/AI coating of steel wires |
||||
Compound of corrosion protection |
95% Zn / 5% AI |
||||
Coating |
min.150g/㎡ |
min.150g/㎡ |
min.150g/㎡ |
||
Mesh edges |
Mesh ebds knotted |
||||
Mesh standard |
||
Roll with |
2m，2.5m，3m，3.5m，4m，4.5m，customizable |
|
Roll length |
10m，20m，30m，as per site requirement customizable |
|
Details Images
Main Components
High-tensile Steel Wire Mes
Is made of the high-tensile steel wire with an ultimate tensile strength of 1770 N/mm2.
Soil or Rock Nails （Steel Anchor）
steel wire mesh can be anchored in accordance with plan with commercial soil or rock nails. Anchor consists of commercially available steel bars ranging from 1.0 to 1.25 ft (25 to 32mm).
Spike Plates
Rigid spike plates reinforced with ribbing ensure optimal load transmission from soil or rock anchors to the Steel Wire Mesmesh.These plates are placed over the anchor heads and tightened to pre-tension the mesh onto the slope.
The plates are galvanized and have dimensions of 13.0''*7.5"*0.3"/0.4"(330mm*190mm*8/10mm), 13.0''*7.08"*0.3"/0.4"(330mm*180mm*8/10mm), 13.0''*7.5"*0.3"/0.4"(330mm*205mm*8/10mm), etc.
Packing & Delivery
Product Application
Function
• Slope stabilization
• Protection against slides breaking out
• Rockfall protection
• Erosion protection
Characteristics of the high-tensile steel wire mesh
●High-tensile steel wire (>256 KSI)
●High tensile strength of the mesh (> 10.2kips/ft)
●Safe force transmission mesh to nail
●Low weight
●Pretensioning of the system possible
●Simple handling
●Specialcorrosion protection
