Help CenterABB 5SHY35L4510 IGCT Press-Pack – Built for Dependable Switching in Medium-voltage Power Converters
Related Products
-
ABB 5SXE07-0164 (GVC714A101) IGCT Gate Unit – High‑reliability Drive and Protection for IGCT Power StacksUS$ 3360.00MOQ: 1 Combo -
ABB 5SHY35L4511 IGCT Module – Press-pack Power Thyristor for Medium-voltage Drives and Grid ConvertersUS$ 3360.00MOQ: 1 Combo
-
ABB 5SHY45L4520 IGCT Module – Reliable High-power Switching for Medium-voltage ConvertersUS$ 3360.00MOQ: 1 Combo
-
ABB IMDS003 Digital Output Slave Module – Reliable DO Control for ABB DCS InstallationsUS$ 1360.00MOQ: 1 Combo
-
ABB IOR810 (P-HB-IOR-80010000) – S800 I/O Gateway Module for HN800US$ 1360.00MOQ: 1 Combo
Warranty: 365 days
Lead time: 1 week if in stock; no more than 1 month at the latest
Payment: 50% advance; balance prior to delivery
Express options: FedEx, UPS, DHL
We typically confirm electrical fit and clamping details before booking. If you’re replacing an installed unit, share your existing gate unit details and stack layout — it helps us pre-validate compatibility and avoid surprises during commissioning.
Press-pack reliability – Fail-safe short-circuit mode and uniform thermal path are preferred in MV stacks.
Low on-state losses – Typically lower conduction loss than comparable IGBT solutions for steady heavy-load duty.
High di/dt and dv/dt handling – Suited for cycloconverters, large drives, and grid-support converters.
4.5 kV-class device – The L45xx designation aligns with ABB’s 4.5 kV voltage class IGCT family.
Service-friendly – Press-pack form factor simplifies replacement without reworking busbars in many cases.
Matched to ABB gate units – Works with dedicated IGCT gate drivers for fast, clean turn-off.
Traceability and documentation – ABB’s labeling and lot data make quality audits straightforward.
| Brand / Model | ABB 5SHY35L4510 |
| Device Type | IGCT press-pack power semiconductor (thyristor family) |
| Voltage Class | 4.5 kV-class (typical for ABB L45xx IGCT series) |
| HS Code | 8541.30 (Thyristors, diacs and triacs) |
| Power Requirements | Not applicable (passive device; driven by dedicated IGCT gate unit) |
| Signal Input / Output | Gate connection to IGCT gate unit; no field I/O on the device itself |
| Communication Interfaces | None on device; gate driver typically accepts electrical/fiber trigger from controller |
| Installation Method | Press-pack clamped between heat sinks/busbars using specified axial force |
| Operating Temperature | Component-level limits per ABB datasheet; storage typically -40 to +125°C |
| Package / Form Factor | ABB press-pack IGCT housing for 4.5 kV-class devices (fits standard IGCT clamps) |
Medium-voltage drives for cement, mining, steel, and marine propulsion
Grid support and FACTS equipment (STATCOM, SVC) where robust switching is needed
High-power rectifier/inverter bridges, cycloconverters, and soft-start solutions
Traction power converters and heavy industrial energy conversion systems
One thing I appreciate is how the 5SHY35L4510 behaves in long-duty applications with frequent thermal cycles — press-pack contact and even pressure distribution seem to keep performance consistent over time, assuming the clamp force is set correctly.
Reliability under stress – Press-pack construction manages thermal and electrical stress better in many MV stacks.
Compatibility – Pairs with ABB IGCT gate units and standard clamps, reducing engineering effort in retrofits.
Lifecycle cost – Lower conduction losses and predictable failure mode can translate to fewer unplanned outages.
Support – Availability of application notes and proven references speeds up commissioning and service.
A maintenance supervisor at a mill summarized it well: “Once we corrected the clamp force and airflow path, we stopped seeing nuisance trips — the IGCT stack just ran.”
Installation & Maintenance GuidelinesCabinet & environment – Use a closed electrical cabinet meeting IEC/UL standards; keep ambient typically within 0–40°C with adequate ventilation or liquid cooling.
Clamping force – Apply ABB-specified axial force using a calibrated tool or load-cell washers; uneven force shortens life.
Contact surfaces – Clean, flat, burr-free copper/aluminum; apply suitable interface material if recommended.
Gate unit – Mount the IGCT gate driver per ABB guidance; minimize loop inductance; verify fiber/electrical trigger integrity.
Wiring & snubbers – Keep busbars short and symmetrical; use ABB-recommended snubber components for voltage shaping.
Cooling – Ensure airflow or liquid flow rates meet thermal design; check for dust clogging and blocked fins.
Routine care – Periodically re-verify clamp torque/force, clean heatsinks, check gate unit firmware and self-tests.
Safety – Lockout/tagout, discharge capacitors, and verify absence of energy before service; observe creepage/clearance.
IGCT Gate Driver Unit (GDU) – Dedicated fast gate unit for 4.5 kV-class IGCTs; provides high di/dt turn-off capability and diagnostic signaling.
Press-Pack Clamping Assembly – Spring or hydraulic clamp calibrated to the required axial force; includes insulated posts and force indicators.
Snubber Network – Film snubber capacitors with damping resistors to shape dv/dt and protect during commutation.
Fiber-Optic Trigger Link – For noise-immune control from the converter protection/control board to the GDU.
Heatsinks / Cold Plates – Air-cooled extrusions or liquid-cooled plates sized for the IGCT’s thermal impedance and duty cycle.
Manufactured by ABB under ISO 9001 quality systems
RoHS-compliant component (typical for ABB IGCT families)
CE/UL apply at equipment level; bare semiconductors typically are not CE-marked
Warranty: 365 days (repair/replace policy aligned with inspection findings)
If you’re confirming a direct replacement, share your stack position, gate unit type, cooling method, and any historic fault logs. It usually saves a round of emails and helps us ship the right unit faster.
