Help CenterABB 5SHY35L4511 IGCT Module – Press-pack Power Thyristor for Medium-voltage Drives and Grid Converters
Related Products
-
ABB 5SHY45L4520 IGCT Module – Reliable High-power Switching for Medium-voltage ConvertersUS$ 3360.00MOQ: 1 Combo -
ABB IMDS003 Digital Output Slave Module – Reliable DO Control for ABB DCS InstallationsUS$ 1360.00MOQ: 1 Combo
-
ABB IOR810 (P-HB-IOR-80010000) – S800 I/O Gateway Module for HN800US$ 1360.00MOQ: 1 Combo
-
ABB KUC755AE117 Control Board – Reliable Replacement for ACS/Drive System ControlUS$ 12360.00MOQ: 1 Combo
-
ABB MPRC086444-005 Industrial Control Module – Reliable Spare for ABB Automation RacksUS$ 9360.00MOQ: 1 Combo
Warranty: 365 days
Lead time: 1 week if in stock; no more than 1 month at the latest
Payment: 50% advance payment, full payment before delivery
Shipping: FedEx, UPS, DHL (express options available)
Packaging: ESD-safe, shock-absorbing packing for press-pack devices
Press-pack construction – Metal-ceramic package with uniform pressure contact; no wire bonds, typically excellent thermal cycling and short-circuit robustness.
IGCT switching behavior – Gate-commutated turn-off provides fast, clean commutation compared to classic GTOs, helping reduce losses and snubber stress.
High-voltage class (4.5 kV family) – Well-suited for MV drive DC-link levels and grid converter topologies using series stacking.
Low conduction losses for high current – In many cases results in lower system losses versus equivalent IGBT stacks at the same voltage class.
Predictable failure mode – Press-pack devices tend to fail short, which system designers often prefer for series strings and fault management.
Mature ecosystem – Works with dedicated ABB gate units, proven clamps, and standard heat-sink assemblies used across MV platforms.
| Brand / Model | ABB 5SHY35L4511 (IGCT, press-pack) |
| HS Code | 8541.30 (Thyristors, other than photosensitive) |
| Voltage Class | 4.5 kV family (typical for the 45xx series) |
| Power Requirements | Passive device; requires external gate unit. Gate unit supply typically 24 VDC. |
| Operating Temperature | Case temperature up to 125°C is common for ABB IGCTs; observe datasheet derating and thermal limits. |
| Signal I/O Types | High-current gate drive via coaxial interface; main power path through press-pack anode/cathode electrodes. |
| Communication Interfaces | None on device. Gate unit side typically uses fiber-optic command/feedback. |
| Installation Method | Press-pack clamping between heat sinks using calibrated disc springs; follow specified clamping force and torque. |
| Package Size | ABB press-pack frame; 91 mm class is common for 4.5 kV IGCTs (verify with the specific 5SHY35L4511 drawing). |
You might notice this device shows up in equipment where downtime is expensive and switching losses add up quickly:
Medium-voltage drives for compressors, pumps, rolling mills, and marine propulsion
Static VAR Compensators (SVC) and STATCOM systems for grid stability
High-power rectifiers and DC supplies in metals, mining, and chemistry
Wind turbine and test-bench converters in the multi-megawatt range
Traction auxiliary converters and heavy industrial UPS where robust press-pack devices are preferred
Feedback from a maintenance lead at a steel plant: “Swapping to the ABB IGCT package cut our thermal failures. Clamping setup needs care, but once dialed in, it’s been steady for years.”
Reliability in harsh duty – Press-pack architecture handles thermal cycling and current surges better in most MV stacks.
Compatibility – Fits established ABB gate-unit ecosystems and standard mechanical clamps, simplifying retrofits.
Cost of ownership – Lower conduction losses and predictable fault behavior can reduce snubber stress and downtime, which typically saves more than the initial device delta.
Long-term support – ABB’s IGCT family has stable availability and documentation, which makes lifecycle planning easier.
Cabinet & environment – Install in a sealed cabinet with filtered airflow or liquid-cooled heat sinks. Keep ambient dust and moisture low; typical design target is clean, dry air,
Clamping – Use a calibrated press system with disc springs. For this frame size, clamping forces are usually in the 25–35 kN range; confirm the exact value in the ABB drawing for 5SHY35L4511.
Gate drive – Pair with the correct ABB gate unit for 4.5 kV IGCTs. Ensure short, low-inductance gate connections and verify fiber-optic command polarity and interlocks at commissioning.
Wiring – Keep busbars laminated and symmetrical. Minimize loop inductance around the device to improve di/dt control and reduce snubber stress.
Cooling – Use flat, lapped heat-sink surfaces. Apply approved thermal interface material (thin, uniform). Check temperature rise under load and stay within case temperature limits.
Routine checks – Inspect clamping force after initial thermal cycles, clean dust from heat sinks, verify gate unit health (fiber signal, DC supply), and keep firmware up to date when applicable.
Safety – Lockout/tagout the DC link. Discharge snubbers and DC capacitors, and use appropriate HV PPE. IGCTs can store charge; treat the stack as live until proven safe.
RoHS: Typically compliant; material declaration available on request.
ISO: Manufactured in ISO 9001 certified facilities.
CE/UL: As a semiconductor component, CE/UL marking may not apply to the device itself; system-level certification is handled by the equipment manufacturer.
Warranty: 365 days (device-level warranty as stated above).
Gate Unit for 4.5 kV IGCT – Fiber-optic controlled drive unit with 24 VDC supply, tailored gate current profile, and protection interlocks.
Press-pack clamping set – Calibrated disc springs, load washers, and insulated fixtures matched to the device frame size.
Laminated busbars and snubber network – Optimized to limit stray inductance and voltage overshoot during turn-off.
High-performance heat sinks – Air- or liquid-cooled, lapped surfaces for uniform contact pressure and low thermal resistance.
Fiber-optic transceivers – Compatible transmitter/receiver pairs for command and status channels between controller and gate unit.
