Test equipment function：
The equipment is designed and manufactured according to ANSI/BHMA A156.1Clause 6.6, which meets the requirements of the standard.
Used to test the durability of the Electrified hinge, connect the rated power supply on the hinge over the line, perform the switch test on the hinge, and check the electrical conductivity during the life test of the hinge switch.
Equipment parameters：
Model：ZNBHMA-3G
Size：L 0.8 m * W 0.6 m * H 1.3 m
PLC control: Panasonic, test scheme and parameter setting, fault monitoring and shutdown
Test speed: 10 times/min, adjustable
Power supply: AC, DC, pulse, configurable
Frame：stand-alone test stand
Test station: 3 stations
Touch screen (HMI) : set the number of life times, keep counting display after power failure
PLC: Panasonic ; Pneumatic parts: Airtac brand.
Test standards： ANSI/BHMA A156.1Clause 6.6
