Help CenterABB UNS4684a-P;V.1 PCB – Reliable Plug-in Control Board for ABB Rack-based DCS/automation Systems
Related Products
-
ABB XVC767AE105 (3BHB007209R0105) – Control Board for ACS800/Multidrive SystemsUS$ 10416.00MOQ: 1 Pallet -
ABB PM860AK01 3BSE066495R1 – AC 800M CPU Kit for Reliable, Scalable Process ControlUS$ 4816.00MOQ: 1 Pallet
-
ABB PM860AK01 3BSE066495R1 – AC 800M CPU Kit for Reliable, Scalable Process ControlUS$ 4816.00MOQ: 1 Pallet
-
ABB S-113H 3BHB018008R0003 – Gate Driver Board for ABB Industrial Drive Inverter StacksUS$ 170460.00MOQ: 1 Pallet
-
ABB PU515A RTA Board (3BSE032401R1) – Controller-internal Interface Board for ABB DCS Maintenance and UpgradesUS$ 5880.00MOQ: 1 Piece
Warranty: 365 days
Lead time: 1 week if in stock; no more than one month at the latest
Payment: 50% advance; full balance before delivery
Courier options: FedEx, UPS, DHL
Packaging: ESD-safe packing with foam protection, moisture barrier bag where applicable
Form-fit replacement for ABB racks – Plug-in PCB designed for ABB control backplanes; helps minimize downtime during swaps.
Backplane-powered design – Typically draws regulated logic power (5 VDC class) directly from the rack; no external PSU wiring.
Stable V.1 hardware revision – Version consistency usually improves compatibility with installed systems and firmware baselines.
Industry-rated construction – Built for continuous operation in control cabinets; seems to be robust against common electrical noise in many cases.
Service-friendly – Edge-connector installation and standard ABB fixing points; quick to remove/insert for on-site maintenance.
| Brand / Model | ABB UNS4684a-P;V.1 PCB |
| HS Code | 85389000 (Parts for control panels/boards, electrical control) |
| Power Requirements | Backplane supplied; typically 5 VDC logic rail (no separate field power on board) |
| Operating Temperature | 0 to +55 °C typical for cabinet-mounted electronics |
| Signal I/O Types | Backplane data/control lines; no direct field-wiring terminals on the PCB |
| Communication Interfaces | ABB proprietary rack/backplane bus (system-specific) |
| Installation Method | Plug-in PCB for ABB rack; secured at the front; observe ESD handling |
| Approx. Size & Weight | Plug-in card, lightweight (<0.5 kg typical) |
This board is commonly used in ABB DCS/automation cabinets across power generation units, chemical and petrochemical plants, pulp & paper lines, metals processing, and general manufacturing. One thing I appreciate is how it supports fast hot-swap maintenance in many cabinets, which helps operations teams avoid extended shutdowns. In retrofit projects, it’s typically chosen to keep legacy control loops stable while other parts of the system are incrementally modernized.
Reliability – ABB boards are known for consistent uptime; this model is often used to restore stable operation after intermittent faults.
Compatibility – Version V.1 usually aligns with installed firmware and neighboring modules, reducing integration risk.
Cost Control – Direct replacement lowers engineering time and commissioning cost compared with redesigning I/O or rewriting logic.
Technical Support – We provide pre-shipment photos, test reports where available, and guidance for rack position and orientation.
Maintenance engineer feedback: “Swapped the UNS4684a-P;V.1 during a short window—seated cleanly, system recognized it immediately, and our loop stabilized within minutes.”
Cabinet environment – Install in a clean, ventilated control cabinet. Keep ambient within 0–55 °C and 5–95% RH non-condensing, typical for industrial control rooms.
Wiring – No field wiring to the board; it mates with the rack backplane. Verify slot assignment and keying before insertion.
ESD handling – Use grounded wrist strap and ESD mat. Avoid touching components and connector pins.
Seating & fixation – Insert evenly along guides; secure front fasteners to prevent vibration-related issues.
Routine care – Quarterly cabinet dust removal (dry, oil-free air), visual inspection for connector wear, and periodic firmware/config checks if applicable.
Spare policy – Keeping one board per critical cabinet on the shelf typically reduces MTTR significantly.
For a seamless fit, pair this PCB with the matching ABB rack/backplane and terminal base units used in your system. If you share the installed controller family and slot map, we can recommend compatible backplanes, carrier frames, and any required front-panel hardware for your cabinet standard.
Quality & CertificationsCE compliant for industrial EMC/safety (typical for ABB control PCBs)
RoHS conformity on most later production runs
Manufactured under ISO 9001 quality systems
Materials typically UL-recognized laminates
Manufacturer’s hardware warranty: 12 months from shipment
