Help CenterGerman Industrial Grade Shot Blasting Machine Roller Pass Through Steel Plate Pre-treatment Effect is Good
Related Products
-
Burr Cleaning Automatic Roller Sandblasting Machine Through Type Multi Spray Gun Sandblasting Machinery FactoryUS$ 20000MOQ: 1 Set -
The Rust Removal Roller Conveyor for Die-casting Parts Has a Tight Structure and a Short Delivery CycleUS$ 20000MOQ: 1 Set
-
Q69 Series Rust Removal and Cleaning Metal Surface H-beam Ball Bearings Roller Conveyor Through Shot Blasting MachineUS$ 20000MOQ: 1 Set
-
Automatic Direct Shot Blasting Machine Customized Frame H-beam H-beam Drum Conveyor Shot Blasting MachineUS$ 20000MOQ: 1 Set
-
Efficient Surface Rust Removal Roller Through Shot Blasting Machine With One Click Start OperationUS$ 20000MOQ: 1 Set
Fully automatic steel structure H BEAM through type steel plate shot blasting machine, metal casting shot blasting large cleaning machine
Parameters and information of various types of Roller conveyor shot blasting machines
Roller conveyor shot blasting machine is a multifunctional pre-treatment equipment for cleaning steel plates, steel structures, profiles, steel pipes, etc.
It is characterized by the use of power drum transport, which can pass heavy, ultra.long workpieces.Widely used in automobile, tractor, motor, valve and other industries.
After shot blasting, the corrosion resistance and fatigue resistance of the workpiece and metal components can be improved
Model number |
RG0808 |
RG0612 |
RG0816 |
RG1018 |
RG1525 |
|
Workpiece |
Width and Height(mm) |
600*600 |
400*1000 |
600*1400 |
800*1600 |
1300*2300 |
Length(mm) |
3000-12000 |
3000-12000 |
3000-12000 |
3000-12000 |
3000-12000 |
|
Blasting wheel |
Blasting Capacity(kg/min) |
4*200 |
6*200 |
8*200 |
8*200 |
10*200 |
Power(kw) |
4*11 |
6*11 |
8*11 |
8*11 |
10*11 |
|
Roller table allows load (kg/m) |
500 |
500 |
1000 |
1000 |
1500 |
|
Roller conveyor speed(m/min) |
0.4-4 |
0.4-4 |
0.4-4 |
0.4-4 |
0.4-4 |
|
Ventilation Capacity(m³/h) |
12000 |
15000 |
18000 |
18000 |
24000 |
|
Pellet material circulation(T/h) |
50 |
70 |
120 |
120 |
150 |
|
Total Power (kw) |
≈70 |
≈120 |
≈125 |
≈130 |
≈200 |
|
What industries is the shot blasting machine suitable for?
Full analysis of applicable scenarios for shot blasting and sanding machines, which are used in various industries
Shot blasting machines, as surface treatment equipment, are widely used in multiple industries.
It can clean, strengthen, and pre treat the surface of the workpiece, improving product quality and service life.
Next, Yancheng Ruigang Machinery Co., Ltd. will take a look at the specific scenarios it is suitable for:
Metal processing industry
-Surface cleaning of castings, forgings, stamped parts and other workpieces
-Remove oxide scale, rust, and burrs to make the surface smoother
-It can also improve the surface roughness of the workpiece and enhance the adhesion of subsequent coatings
Mechanical manufacturing field
-Surface strengthening treatment of precision parts such as gears and bearings
-Surface cleaning and refurbishment of molds, fixtures, and other tools
-Removal of welding slag and surface pretreatment of welded parts
Automotive and Shipping Industry
-Rust removal, paint removal, and surface strengthening of automotive components
-Surface pretreatment before anti-corrosion treatment of ship steel structures
-Surface treatment of large metal components such as containers and frames
Building Decoration Industry
-Surface texture processing of decorative materials such as stone and ceramics
-Surface drawing and shot blasting treatment of metal sheets
-Surface texture treatment of sculptures and handicrafts
Aerospace field
-Surface cleaning and strengthening of aircraft engine components
-Surface pretreatment and rust prevention treatment of spacecraft structural components
-Surface treatment of special materials such as titanium alloys
The shot blasting machine can adapt to various workpiece and surface treatment requirements through different ejection parameters and equipment configurations. It can be seen in industries such as metal processing, machinery manufacturing, automobiles, ships, and building decoration.
Yancheng Ruigang Machinery Co., Ltd. can help users choose and use shot blasting machines reasonably, effectively improve production efficiency and product quality, and reduce subsequent processing costs.
