Fully automatic steel structure H BEAM through type steel plate shot blasting machine, metal casting shot blasting large cleaning machine
Parameters and information of various types of Roller conveyor shot blasting machines
Roller conveyor shot blasting machine is a multifunctional pre-treatment equipment for cleaning steel plates, steel structures, profiles, steel pipes, etc.
It is characterized by the use of power drum transport, which can pass heavy, ultra.long workpieces.Widely used in automobile, tractor, motor, valve and other industries.
After shot blasting, the corrosion resistance and fatigue resistance of the workpiece and metal components can be improved
Model number |
RG0808 |
RG0612 |
RG0816 |
RG1018 |
RG1525 |
|
Workpiece |
Width and Height(mm) |
600*600 |
400*1000 |
600*1400 |
800*1600 |
1300*2300 |
Length(mm) |
3000-12000 |
3000-12000 |
3000-12000 |
3000-12000 |
3000-12000 |
|
Blasting wheel |
Blasting Capacity(kg/min) |
4*200 |
6*200 |
8*200 |
8*200 |
10*200 |
Power(kw) |
4*11 |
6*11 |
8*11 |
8*11 |
10*11 |
|
Roller table allows load (kg/m) |
500 |
500 |
1000 |
1000 |
1500 |
|
Roller conveyor speed(m/min) |
0.4-4 |
0.4-4 |
0.4-4 |
0.4-4 |
0.4-4 |
|
Ventilation Capacity(m³/h) |
12000 |
15000 |
18000 |
18000 |
24000 |
|
Pellet material circulation(T/h) |
50 |
70 |
120 |
120 |
150 |
|
Total Power (kw) |
≈70 |
≈120 |
≈125 |
≈130 |
≈200 |
|
What are the performance advantages of the through shot blasting rust removal machine?
Performance analysis of through shot blasting rust removal machine: 5 advantages to make rust removal more efficient
Through shot blasting rust removal machine as the core equipment for industrial rust removal
Widely used in industries such as steel structures and shipbuilding
What are its performance advantages? Today, Yancheng Ruigang Machinery Co., Ltd. will take you on a deeper understanding~
Advantage 1: Efficient rust removal improves production efficiency
The through type shot blasting machine adopts a multi head design
Each throwing head is equipped with high hardness and wear-resistant pellets
Can simultaneously clean multiple surfaces of the workpiece in all directions
According to data from the Machinery Association of Yancheng Ruigang Machinery Co., Ltd
A through type shot blasting machine can process 50-80 tons of steel per hour
The rust removal efficiency is more than three times that of traditional sandblasting process
Advantage 2: High degree of automation reduces labor costs
The device supports continuous conveying operations
Automated process from workpiece loading to rust removal completion
Only 1-2 operators are needed to monitor the operation of the equipment
Compared to manual sandblasting, it can save approximately 150000 to 200000 yuan in labor costs annually
Especially suitable for large-scale standardized production
Advantage 3: Environmental protection, energy conservation, and reduction of pollution emissions
Adopting a closed dust removal system
The recycling and utilization rate of pellets reaches over 90%
Control dust emissions below national environmental standards
At the same time, the energy consumption of the equipment is reduced by 40% compared to traditional sandblasting
Both environmentally friendly and able to save energy expenses for enterprises
Advantage 4: Strong adaptability of workpieces and wide applicability
Support various profiles such as H-beams, steel plates, and steel pipes
Can be adjusted by adjusting the conveying speed and ejection angle
Meet the rust removal requirements of workpieces of different sizes
Even complex shaped components can be uniformly cleaned
Avoiding the problem of inadequate corner treatment in traditional craftsmanship
Advantage 5: Intelligent control system operates safely and conveniently
Equipped with PLC intelligent control system
Pre set rust removal parameters, one click start
The equipment is equipped with multiple safety protection devices
Such as emergency stop button, overload protection, etc
Even beginners can quickly get started with the operation
Summary: The through type shot blasting rust removal machine has advantages such as high efficiency, environmental protection, and intelligence
Has become the mainstream choice for industrial rust removal
Whether it is a large steel structure enterprise or a small and medium-sized manufacturing factory
By configuring the equipment reasonably, production quality and efficiency can be improved
#Shot blasting and rust removal equipment # Industrial machinery # Surface treatment technology
