ABB DAPI100 3AST000929R109 Ethernet Communicator Interface Module

ABB DAPI100 3AST000929R109 is a data acquisition and processing module that plays an important role in industrial automation control systems. As a high-quality product under ABB, it integrates advanced industrial data processing technologies and rich industry experience. It is specially designed to meet the needs for precise acquisition, rapid processing, and reliable transmission of various types of data in industrial production. In complex industrial environments, this module can provide comprehensive and accurate data support for automation systems, and is one of the key components ensuring the smooth and efficient operation of industrial production processes, with wide applications in multiple industrial fields.

•


• Electrical Parameters: It is powered by 24V DC, a standard voltage that is compatible with most industrial power supply systems, providing reliable power guarantee for the stable operation of the module. In terms of data acquisition, it supports multiple analog input signals, such as 4-20mA current signals and 0-10V voltage signals, which can accurately capture signals from various sensors such as temperature, pressure, and liquid level sensors, with high acquisition accuracy to ensure data correctness.
• Physical Parameters: The product has a compact size of 110mm×90mm×60mm. Its small shape allows for easy installation in control cabinets or equipment with limited space, saving installation space. The shell is made of sturdy industrial-grade materials, with certain vibration and impact resistance, enabling it to withstand mechanical stress in industrial environments.
• Environmental Parameters: The operating temperature range is -10℃ to +60℃, and it can maintain stable performance within a relatively wide temperature range, working normally both in cold winter workshops and hot summer production environments. The relative humidity adaptation range is 5%-95% (non-condensing), which can cope with industrial scenarios with different humidity conditions such as humidity or dryness, ensuring the reliable operation of the module in various environments.

•


• Efficient Data Acquisition and Processing: The DAPI100 3AST000929R109 module has strong data acquisition capabilities, capable of real-time and accurate acquisition of multiple analog signals. At the same time, it is equipped with an efficient processing unit inside, which can quickly process and convert the acquired data, transforming the original signals into digital signals recognizable by the system, providing timely and accurate data basis for subsequent control decisions.
• Reliable Data Transmission: It supports multiple industrial communication protocols such as Modbus RTU and PROFINET, enabling seamless connection and efficient data transmission with other automation equipment such as PLCs and upper computers. The data transmission process is stable and reliable, not easily affected by electromagnetic interference in industrial environments, ensuring the accuracy and timeliness of information transmission.
• Good Compatibility and Expandability: It can be compatible with various ABB automation systems and industrial equipment of other brands, facilitating integration into existing industrial automation networks. In addition, the module also has certain expandability. Users can increase input channels or combine with other functional modules according to actual needs to meet more complex industrial data acquisition and processing requirements.
• Comprehensive Self-Protection and Diagnosis: It has built-in overvoltage and overcurrent protection circuits. When the input signal is abnormal, it can respond quickly to protect the module itself and connected equipment from damage. At the same time, it is equipped with a self-diagnosis function, which can monitor the operating status of the module in real-time, such as power failure and communication abnormalities. Once a problem is detected, it will send an alarm signal in a timely manner, facilitating technicians to troubleshoot and maintain, and reducing equipment downtime.

•


• Process Control Field: In the production processes of chemical, petroleum, natural gas and other industries, it can be used to collect key parameters such as temperature, pressure, and flow of reaction kettles, and transmit the data to the control system to provide support for the precise regulation of the production process. For example, in chemical production, this module is used to collect real-time temperature and pressure data in the reaction kettle, and the control system adjusts the feed amount and heating power in a timely manner based on these data to ensure the stable progress of chemical reactions.
• Manufacturing Industry: In various production lines, it is used to collect operating parameters of production equipment, such as motor speed and equipment vibration frequency, to realize condition monitoring of production equipment. When equipment parameters are abnormal, the control system can issue an early warning in a timely manner, so that operators can take measures to avoid production interruption caused by equipment failure, and improve production efficiency and product quality.
• Energy Industry: In fields such as electric power and new energy, it can be used to collect operating data of power generation equipment and transmission equipment, such as voltage, current, and temperature parameters of generators, as well as output voltage and current data of photovoltaic panels in photovoltaic power stations. Through the analysis and monitoring of these data, the safe and stable operation of energy production and transmission is ensured, and energy utilization efficiency is improved.
• Water Treatment Industry: In sewage treatment plants and waterworks, it is used to collect data such as water quality indicators and the operating status of water pumps. For example, it monitors parameters such as pH value and turbidity of sewage, and controls the dosage of dosing equipment based on the data to ensure that the sewage treatment effect meets the standards; at the same time, it monitors the pressure and flow of water pumps to ensure the stable operation of the water treatment system.
