ABB UFC760BE01 3BHB007030R0001 Fieldbus Communication Module

ABB UFC760BE01 3BHB007030R0001 is a high-performance inverter converter that holds an important position in the field of industrial automation and electric drive. It focuses on providing precise and efficient power conversion solutions for motor drives of various industrial equipment. By converting the input alternating current into flexibly adjustable alternating current output, this module can accurately control key operating parameters such as motor speed and torque, thereby ensuring that the motor operates stably and efficiently under different working conditions. It is widely used in various industries such as manufacturing, process industry, and transportation, playing a key role in improving the automation level of industrial production processes, optimizing equipment operation efficiency, and reducing energy consumption. It is an indispensable important component in modern industrial automation systems.

•


• Power Handling Capacity: This module has a strong power handling capacity, capable of handling up to 700kW of power, which can meet the power demand of large industrial equipment and high-load operation scenarios. Whether it is driving high-power pumps, fans, or operating complex production line equipment, it can stably provide the required power support.

• Operating Voltage: The designed and adapted operating voltage is 380V AC. This standard voltage specification meets the power supply requirements of most industrial power grids, ensuring the wide applicability of the module in various industrial environments. It can be directly connected to existing industrial power systems without complex voltage conversion equipment.

• Frequency Range: The output frequency range can reach 400Hz, which can flexibly adjust the operating speed of the motor. By precisely controlling the output frequency, continuous adjustment of the motor speed can be achieved to meet the diverse needs of different processes for motor operating speed. For example, in some automated production lines that require high-precision speed control, it can accurately match the production rhythm.

• Inverter Efficiency: It has an extremely high inverter efficiency of over 98%. This means that in the process of power conversion, most of the input electrical energy can be efficiently converted into output electrical energy, reducing energy loss. It not only reduces the operating cost of the equipment but also improves energy utilization efficiency, meeting the requirements of modern industry for energy conservation and environmental protection.

• Control Modes: It supports two modes: vector control and open-loop control. In vector control mode, the module can decouple and control the magnetic field and torque of the motor, achieving high-precision control of the motor, making it excellent in dynamic response and low-speed performance. It is suitable for occasions with extremely high requirements for motor control accuracy, such as the drive control of CNC machine tools. Open-loop control mode is relatively simple and low-cost, suitable for general application scenarios that do not require high control accuracy but need to quickly realize motor start-stop and speed adjustment.

• Protection Level: The protection level reaches IP21, which is suitable for indoor installation scenarios in general industrial environments. This protection level can effectively prevent the intrusion of solid foreign objects larger than 12mm and protect the equipment from damage caused by vertically dripping water droplets, providing basic protection for the stable operation of the module in conventional industrial environments.

• Cooling System: It adopts natural convection cooling method. This cooling method does not require additional cooling fans or complex cooling circulation devices, and relies on natural convection between the module itself and the surrounding air for heat dissipation. Its advantages are simple structure, high reliability, no additional energy consumption, and no risk of shutdown caused by problems such as fan failure or coolant leakage during operation, which can maintain stable heat dissipation effect during long-term operation.

• Operating Temperature: The operating temperature range is -20℃ to +50℃, which can adapt to relatively wide environmental temperature conditions. Whether in cold northern industrial areas or hot southern industrial sites, this module can work normally, ensuring the continuous and stable operation of the motor drive system in industrial production processes under different climatic conditions.

• Overall Dimensions and Weight: The overall dimensions of the module are 480mm in length × 250mm in width × 250mm in height. It has a compact structure, occupies small space, and is convenient for installation and layout in control cabinets or inside equipment. Its weight is about 35kg, which, while ensuring sufficient strength and performance, has good handling and installation convenience.

•


• Advanced Digital Control Technology: It has built-in advanced digital control chips and algorithms, which can quickly and accurately process input signals, thereby achieving precise control of the inverter output. This precise control ensures the stability of the motor during operation, effectively reduces motor vibration and noise, prolongs the service life of the motor, and improves the control accuracy and reliability of the entire drive system.

• Efficient Energy Management: It integrates an advanced energy management system, which can real-time monitor the operating status and load conditions of the motor, and automatically adjust the output power of the inverter according to actual needs. When the motor is running under light load, it reduces the output power to reduce energy consumption; when the motor is running under heavy load, it provides sufficient power support in time to ensure stable operation of the motor. Through this intelligent energy management method, the energy consumption of industrial equipment can be significantly reduced, saving operating costs for enterprises.

• Comprehensive Protection Functions: It is equipped with a complete protection mechanism, including overvoltage protection, overcurrent protection, overload protection, overheating protection, etc. When abnormal conditions such as excessively high input voltage, excessively large output current, motor overload, or excessively high module temperature are detected, the protection function will start immediately, quickly cut off the circuit or take corresponding adjustment measures to avoid equipment damage due to faults, effectively ensuring the safety of equipment and personnel, and improving the reliability and stability of system operation.

• Flexible Communication Interfaces: It is equipped with a standard RS-485 communication interface and can optionally be equipped with an Ethernet interface. Through these communication interfaces, the module can perform real-time data interaction with upper-level control systems (such as PLC, DCS, etc.) to realize remote monitoring and control. Operators can remotely set the operating parameters of the module and monitor the operating status of the motor through the upper computer, timely detect and handle potential fault problems, and improve the automation level and management efficiency of the production process.

• Good Compatibility: The design fully considers compatibility with various motors, and can seamlessly connect and work with AC motors of different types and brands. Whether it is an ordinary asynchronous motor or a high-performance synchronous motor, this module can optimize control according to the characteristics of the motor, exert the best performance of the motor, and is suitable for various complex industrial automation system integration projects.
