SR469-P5-HI-A20-E Multilin Series Motor Management Relays

SR469-P5-HI-A20-E Multilin Series Motor Management Relays thumbnail-1
SR469-P5-HI-A20-E Multilin Series Motor Management Relays thumbnail-2
SR469-P5-HI-A20-E Multilin Series Motor Management Relays thumbnail-3
SR469-P5-HI-A20-E Multilin Series Motor Management Relays thumbnail-4
SR469-P5-HI-A20-E Multilin Series Motor Management Relays thumbnail-5
SR469-P5-HI-A20-E Multilin Series Motor Management Relays photo-1
SR469-P5-HI-A20-E Multilin Series Motor Management Relays photo-2
SR469-P5-HI-A20-E Multilin Series Motor Management Relays photo-3
SR469-P5-HI-A20-E Multilin Series Motor Management Relays photo-4
SR469-P5-HI-A20-E Multilin Series Motor Management Relays photo-5
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Material:
Other, Global universal model
Condition:
Other, Global universal model
Task:
Other, Global universal model
Contact Supplier Request Quote Chat Now
Guizhou Yuanmiao Automation Equipment Co., Ltd.
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material Other, Global universal model
Condition Other, Global universal model
Task Other, Global universal model
Mathematical Model Other, Global universal model
Signal Other, Global universal model
Customized Non-Customized
Structure Other, Global universal model
Operating temperature -40℃~+85℃
Humidity 5%~95% (non-condensing)




Many products are not on the shelves yet, please contact us for more models.




    The SR469-P5-HI-A20-E is a motor management relay from GE Multilin series, primarily used for protecting and controlling electric motors, and is suitable for fields such as industrial automation and power systems. Here are the detailed specifications:

    • Product Parameters:

      • Rated Voltage: 90-300VDC or 70-265VAC.

      • Rated Current: 5A or 1A.

      • Operating Frequency: 48-62Hz.

      • Protection Rating: IP54 or IP20.

      • Dimensions: 230mm × 165mm × 80mm.

      • Weight: Approximately 2.2 kg.

      • Communication Interfaces: Supports RS485, RS232, Ethernet, etc.

      • Operating Temperature Range: -40°C to +85°C.

      • Storage Temperature Range: -40°C to +125°C.

    • Product Specifications:

      • Input Voltage Range: 90-300VDC or 70-265VAC.

      • Output Voltage Range: 4-20mA or analog output.

      • Analog Outputs: Four analog outputs.

      • Protection Functions: Equipped with overload protection, short-circuit protection, ground fault protection, stall protection, etc.

      • Mounting Method: DIN rail mounting.



     SR469-P5-HI-A20-E (1)



    • Product Features:

      • High Performance: "HI" indicates enhanced performance, featuring high sensitivity and fast response.

      • High Reliability: Suitable for harsh environments, manufactured with high-temperature and corrosion-resistant materials, equipped with multiple protection mechanisms, and has a long service life.

      • Versatility: Provides multiple protection functions and flexible communication interfaces.

      • Ease of Use: Supports hot swapping, making installation and maintenance convenient. The front panel is equipped with a large LCD display and multiple control buttons for easy operation and monitoring.

      • Modular Design: Facilitates maintenance and replacement of components.




    GE-SR469-P5-HI-A20-E 3

    •
