GE IC695CPL410 high-performance controller module

The IC695CPL410, a high-performance controller module of the GE PACSystem RX3i series, features rich and flexible input/output interface types, supporting multiple industrial communication protocols and device connections. The following is a detailed description of its interface types:

• 3 independent Ethernet ports, all supporting 10/100/1000 Mbps adaptive transmission rates.

• Port 1: Main communication port with a standard RJ-45 interface, used to connect to host computers, SCADA systems, or enterprise networks.

• Ports 2/3: Support embedded switch functions, enabling redundant ring networks (MRP/PNSR protocols) to enhance network reliability.

• Real-time industrial protocols: PROFINET IO Controller (with hot standby), Ethernet/IP, Modbus TCP, DNP3.

• Data exchange protocols: Ethernet Global Data (EGD), OPC UA Server (supporting non-transparent redundancy).

• Remote access: Supports standard network protocols such as SSH, HTTPS, and SNMP.

• 2 independent serial ports, supporting optional RS-232/RS-485 configurations (set via software).

• Physical interfaces: 9-pin D-sub connector (RS-232) and 15-pin D-sub connector (RS-485).

• Industrial protocols: Modbus RTU Master/Slave, SNP (S90-30 Network Protocol).

• Custom communication: Supports user-defined ASCII or binary protocols for legacy device integration.

• 1 USB 2.0 Host port with a standard Type-A interface.

• Program download/upload: Connect to programming devices (e.g., laptops) via a USB programming cable.

• Data storage: Supports external USB drives for recipe management, log recording, or firmware updates.

• Debugging tools: Can connect to a USB-to-serial adapter for debugging other serial devices.

• PCI bus interface: Connects to RX3i series I/O modules, supporting high-speed data transmission (bandwidth up to 132 MB/s).

• Compatibility: Enables mixed installation of RX3i and Series 90-30 modules (via adapters), protecting legacy investments.

• Local I/O: Supports up to 32 I/O modules (with an RX3i rack).

• Remote I/O: Expandable to 255 remote stations via a PROFINET adapter, or connect to remote I/O subsystems via the Genius bus.

• Supports inserting dedicated function cards, such as:

• High-speed counting module (e.g., IC695ACC300): Supports 200kHz input for flying shear control.

• Motion control card: Supports multi-axis synchronous control (with corresponding software libraries).

• Special protocol adapters: Such as PROFIBUS DP master cards, CANopen interface cards, etc.

• Built-in 128×64 pixel OLED display for local status monitoring, showing:

• CPU status, memory usage, network connection status.

• Operation modes (program/run), fault codes, and diagnostic information.

• TPM interface: Supports Trusted Platform Module (TPM 1.2) to enhance system security.

• Power input: 18-30 VDC wide voltage input, with optional redundant power supply (external configuration required).

• Connect to MES/ERP systems via OPC UA protocol to upload production data to the cloud.

• Use the USB interface to connect a 4G/5G router for remote wireless monitoring.

• Insert a motion control card via the PCIe expansion slot to enable collaborative work between robots and PLCs.

• Simultaneously support PROFINET (automation devices) and Modbus RTU (intelligent instruments).

• Dual Ethernet ports form a ring network, with the MRP protocol enabling automatic network fault switching.

• Collaborate with the PNC001 redundancy module to achieve CPU hot standby (switching time <300ms).
