GE IC3600A0AA2 Printed Circuit Board

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Material:

Other

Certification:

Other

Function:

Other

Guizhou Yuanmiao Automation Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Material Other

Certification Other

Function Other

Condition Other

Task Other

Mathematical Model Other

Signal Other

Customized Other

Structure Other

GE IC3600A0AA2 Printed Circuit Board

Basic Information

Product Model: IC3600A0AA2.
Manufacturer: General Electric (GE).
Product Type: Operational amplifier board.
Series: Mark I and Mark II series, which are the beginning of GE's Speedtronic series for steam or gas turbine management.

Appearance Design

Identification Marks: The surface features the GE logo, codes 006/03 and 002/02, and numbers numbered from 10 to 40 in increments of 10.
Pin Arrangement: 25 metal pins are linearly arranged on one side.
Special Design: Two corners are drilled out.

Internal Structure

Transistors: Equipped with 10 transistors, using three different types, among which four transistors are surrounded by heat sinks.
Potentiometers: Four trimmer potentiometers are provided for voltage division.
Other Components: Various capacitors, resistors, and diodes are included, along with a row of eight large carbon composite resistors. Many metal film resistors are also used, and capacitors are typically made of ceramic or polyester materials.

Functions and Applications

Signal Amplification: As an operational amplifier board, its main function is to amplify input signals. It can enhance weak electrical signals to the required amplitude to meet the processing requirements of subsequent circuits, and can be used to amplify various types of signals, such as audio signals and sensor output signals.
Signal Processing: Processes signals, such as filtering, shaping, summation, and difference. By cooperating with other electronic components, various signal processing functions can be achieved to meet different application needs.
Control and Monitoring: In industrial automation control systems, it can be used for controlling and monitoring various parameters. For example, in steam or gas turbine management systems, it processes and amplifies signals of parameters such as temperature, pressure, and flow, providing accurate feedback signals for the control system to achieve precise control and monitoring of the turbine, ensuring its safe and stable operation.

Product Features

High Reliability: The careful design and manufacturing by GE ensure that the circuit board meets strict quality standards, with high reliability and stability, capable of long-term stable operation in various harsh industrial environments.
Strong Compatibility: The design enables it to be seamlessly integrated into different electronic systems, with good compatibility with other devices and components, facilitating system upgrades and expansions for users.
Diversified Functions: The dual operational amplifier configuration increases its functional diversity, meeting the application needs of multiple amplification channels or functions. It has great advantages in electronic setups with limited space or strict requirements on the number of components.

Product Tags: IC3600A0AA2
