Help CenterRENESAS Microcontroller R7F100GLJ2DFB Power Management Agent Supply
Related Products
-
RENESAS R5F1026AASP#55 Microcontroller Microcontroller ConverterUS$ 1 - 500MOQ: 1 Bag -
RENESAS R5F100GEAFB#10 MCU Microcontroller ConverterUS$ 1 - 500MOQ: 1 Bag
-
RENESAS Microcontroller Microcontroller Converter R5F1026AASP#35US$ 1 - 500MOQ: 1 Bag
-
First-level Agent Supply R5F10269ASP#55 RENESAS Microcontroller ConverterUS$ 1 - 500MOQ: 1 Bag
-
MT29F4T08EULGEM4-ITF:G (Micron) 1TBUS$ 1 - 500MOQ: 1 Bag
1. Outline
1.1
Function
Ultra-low power consumption technology
.VoD=1.6 to 5.5 V single supply voltage
.HALT mode
.STOP mode
High-speed wakeup from stop mode is
It's possible.
.SNOOZE mode
RL78 CPU Core
.CISC architecture with 3-level pipeline
Minimum instruction execution time:
Can be from high speed (0.03125 us@
Run at 32 MHz with high speed on-chip
Oscillator clock) to ultra-low speed (30.5 us@
The operating frequency of the subsystem clock is 32.768 KHz)
Multiplication/division/multiple and accumulation instructions
is supported.
Address space: 1 MB
General Registers:
(8-bit register x 8) x 4 memory bank
.On-chip RAM: 12 t0 48 KB
Code flash
* Code flash: 96 to 768 KB
Data block size: 2 KB
.Prohibit block erasing and rewriting (safe
Function)
.On-chip debugging
Self-programming (with boot switch and flash memory
Shield window)
Data flash memory
·Data flash memory: 8KB
Backstage Operation (BGO)
Can execute instructions from the program
Memory flash memory when rewriting data
Number of rewrites: 1.000.000 times (type)
High-speed on-chip oscillator
, select from 32 MHz, 24 MHz, 16 MHz, 12 MHz.
8 MHz. 6 MHz. 4 MHz. 3 MHz. 2 MHz. Or 1 MH2
High precision: +1.0%
(VDD=1.8 to 5.5 V TA=-20 t0+85°C)
Medium speed on-chip oscillator
4 MHz, 2 MHz or 1 MHz (with
Suitability)
Low-speed on-chip oscillator
.32.768 kHz (typical) (with adjustability)
Working ambient temperature
·TA=-40 to +85°C (2D: Consumer Applications)
·TA=-40 t0+105°C (3C: Industrial application)
Power management and reset functions
On-chip power reset (POR) circuit
.On-chip voltage detectors (LvD0 and Lvd1)
Data Transmission Controller (DTC)
Transmission mode:
Normal transmission mode, repeated transmission mode
Block transfer mode
Activation source: Activated by interrupt source
Chain transfer function
Doze mode sequencer (short message)
Calculation and comparison of values
Commands used during processing
Sequencer can implement intermittent operations
RL78/G23 does not have to return to
Working normally.
Process a total of 32 processes in sequence
Use the required commands of the following 21 commands
Different
Sleep mode sequencer provides operation
Low power consumption, no need for use
CPU, flash memory and RAM.
