1. OUTLINE

1.1 Features

Ultra-low power consumption technology

 VDD = single power supply voltage of 1.8 to 5.5 V which

can operate at a low voltage

 HALT mode

 STOP mode

 SNOOZE mode

RL78 CPU core

 CISC architecture with 3-stage pipeline

 Minimum instruction execution time: Can be changed

from high speed (0.04167 s: @ 24 MHz operation with

high-speed on-chip oscillator) to ultra-low speed (1 s:

@ 1 MHz operation)

 Address space: 1 MB

 General-purpose registers: (8-bit register x 8) x 4 banks

 On-chip RAM: 256 B to 2 KB

Code flash memory

 Code flash memory: 2 to 16 KB

 Block size: 1 KB

 Prohibition of block erase and rewriting (security

function)

 On-chip debug function

 Self-programming (with flash shield window function)

Data flash memory Note

 Data flash memory: 2 KB

 Back ground operation (BGO): Instructions are

executed from the program memory while rewriting the

data flash memory.

 Number of rewrites: 1,000,000 times (TYP.)

 Voltage of rewrites: VDD = 1.8 to 5.5 V

High-speed on-chip oscillator

 Select from 24 MHz, 16 MHz, 12 MHz, 8 MHz, 6 MHz,

4 MHz, 3 MHz, 2 MHz, and 1 MHz

 High accuracy: +/- 1.0 % (VDD = 1.8 to 5.5 V, TA = -20

to +85 °C)

Operating ambient temperature

 TA = -40 to +85 °C (A: Consumer applications, D:

Industrial applications)

 TA = -40 to +105 °C (G: Industrial applications) Note

Power management and reset function

 On-chip power-on-reset (POR) circuit

 On-chip voltage detector (LVD) (Select interrupt and

reset from 12 levels)

DMA (Direct Memory Access) controller Note

 2 channels

 Number of clocks during transfer between 8/16-bit SFR

and internal RAM: 2 clocks

Multiplier and divider/multiply-accumulator

 16 bits x 16 bits = 32 bits (Unsigned or signed)

 32 bits x 32 bits = 32 bits (Unsigned)

 16 bits x 16 bits + 32 bits = 32 bits (Unsigned or

signed)

Serial interface

 CSI : 1 to 3 channels

 UART : 1 to 3 channels

 Simplified I2C communication : 0 to 3 channels

 I2C communication : 1 channel

Timer

 16-bit timer : 4 to 8 channels

 12-bit interval timer : 1 channel

 Watchdog timer : 1 channel (operable with the

dedicated low-speed on-chip

oscillator)

A/D converter

 8/10-bit resolution A/D converter (VDD = 1.8 to 5.5 V)

 8 to 11 channels, internal reference voltage (1.45 V),

and temperature sensor Note

I/O port

 I/O port: 18 to 26

(N-ch open drain I/O [withstand voltage of 6 V]: 2,

N-ch open drain I/O [VDD withstand voltage]: 4 to 9)

 Can be set to N-ch open drain, TTL input buffer, and

on-chip pull-up resistor

 Different potential interface: Can connect to a 1.8/2.5/3

V device

 On-chip key interrupt function

 On-chip clock output/buzzer output controller

Others

 On-chip BCD (binary-coded decimal) correction circuit

Note Can be selected only in HS (high-speed main)

mode.

Remark The functions mounted depend on the product.

See 1.7 Outline of Functions.
