Ideal Material Cut Into Any Shape Non-Toxic Silicone Thermal Pad For Medical Devices
- 10000 Piece / Pieces per Month
- Dongguan
- T/T
- 3 days
You May Like
-
Thermal Phase Change Materials
-
Gray High Thermal Conductivity Phase Change Materials PCM
-
Silicone thermal conductive gap pad 1.25W/mK conductivity TIF200 -50 to 200℃ Temp for LED flood light
-
Grey 2.8W/mK thermal conductive gap filler pad for RDRAM memory modules
-
2W/mK conductivity Thermal conductive gap filler TIF400 series for Cooling components to the chassis of frame
-
RosH compliance thermal gap pad with no silicone material for car battery & power supply
Product Details
| Brand Name | ziitek | Place of Origin | China | |
| Model Number | TIF400 series | Material | Other, Silicone | |
| Type | Insulation Sheet | Application | High Temperature | |
| Rated Voltage | high voltage | Tensile Strength | good |
Product Description
Ideal Material Cut Into Any Shape Non-Toxic Silicone Thermal Pad For Medical Devices
Company Profile
Ziitek company is a manufacturer of thermal conductive gap fillers, low melting point thermal interface materials, thermal conductive insulators, thermally conductive tapes, electrically & thermally conductive Interface pads and thermal grease,Thermal Conductive plastic,Silicone Rubber,Silicone Foams,Phase Changing Materials products, with well-equipped testing equipment and strong technical force.
Certifications:
ISO9001:2015
ISO14001: 2004 IATF16949:2016
IECQ QC 080000:2017
UL
Product introduction
The TIF™400 Series thermal silicone pad is a product with both performance and economy. It is a unique thermal pad with low oil permeability, low thermal resistance, high softness and high compliance.It can work stably at -45℃~200℃ and meet the requirement of UL94V0.
Feature
> Good thermal conductive 2.0W/mK
> Moldability for complex parts
> Soft and compressible for low stress applications
> Moldability for complex parts
> Outstanding thermal performance
> High tack surface reduces contact resistance
Applications
> Power supply
> Heat pipe thermal solutions
> Memory Modules
> Mass storage devices
> Automotive electronics
> Set top boxes
> Audio and video components
> IT infrastructure
> GPS navigation and other portable devices
> Medical Devices
| Typical Properties of TIF™480 Series | ||
| Color | Yellow | Visual |
| Construction &Compostion | Ceramic filled silicone elastomer | |
| Thinkness range | 0.020"(0.50mm~0.200"(5.0mm) | ASTM D374 |
| Hardness | 45 Shore 00 | ASTM 2240 |
| Specific Gravity | 2.65 g/cc | ASTM D297 |
| Continuos Use Temp | -45-200℃ | |
| Dielectric BreakdownVoltage @ 1.0mm,AC(v) | ≥5500 | ASTM D149 |
| Dielectric Constant @MHz | 4.7 | ASTM D150 |
| Volume Resistivity（Ohm-cm) | ≥5.3X10¹² Ohm-meter | ASTM D257 |
| Thermal conductivity | 2.0 W/m-K | ASTM D5470 |
| Fire rating | 94 V-0 | UL E331100 |
| Application | Medical Devices | |
| Place of Origin | Guandong,China | |
| Cetification | ROHS,UL | |
| Sample | Samlpe valiable | |
| Size | Customized size | |
Products Thickness:
0.020 inch to 0.200 inch(0.5mm to 5.0mm)
Products Size:
8"*16"(203mm*406mm)
TIF™ series Individual die cut shapes can be supplied.
Peressure Sensitive Adhesive:
Request adhesive on one side with "A1" suffix.
Request adhesive on double side with "A2" suffix.
Reinforcement:
TIF™ series sheets type can add with fiberglass reinforced.
Why Choose us ?
1.Our value message is'' Do it right the First time, total quality control''.
2.Our core competencies is thermal conductive interface materials
3.Competitive advantage products.
4.Condidentiality agreement Bussiness Secrect Contract
5.Free sample offer
6.Quality assurance contract
FAQ
Q: Are you trading company or manufacturer ?
A: We are manufacturer in China
Q: How long is your delivery time?
A: Generally it is 3-7 work days if the goods are in stock. or it is 7-10 work days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra cost?
A: Yes, we could offer samples free of charge
