Product Introduction
The robotic 3D fiber sheet cutting machine adopts a multi-degree of freedom joint structure, and the robotic arm has a large movement space which can perform complex trajectory movement.
The robotic arm is made of a flexible arm that can be bent and rotated in all directions. Its action is similar to that of a human wrist. It can be easily inserted for cutting into the work-piece through a small hole.
This laser cutting machine for stainless steel is widely used in heavy machinery, automobiles, instruments, and electrical appliances, kitchen ware and other metal production.
Product Features
1. The laser cutting machine is safe and reliable, and conforms to European CE standards in processing and non-pollution.
2. The base of the laser cutting machine for stainless steel moving parts is made of a full granite structure; it has high precision and stability.
3. The cutting head and optical lens of the laser cutting machine for stainless steel is designed for fine machining which ensures fine metal processing efficiency.
4. With 6-axis working, the processing range of the laser cutting machine for stainless steel is large, the reach distance is long, the bearing capacity is strong, and 3D trajectory cutting can be performed in the working space.
5. The processing speed and positioning of the laser cutting machine for stainless steel can be adjusted and the product rate is high.
6. This laser cutting machine for stainless steel adopts Switzerland’s imported laser cutting head, which ensures that the laser is always in focus and the cutting effect is guaranteed.
7. The whole laser cutting machine for stainless steel is equipped with a manual lubricating system to reduce the wear of moving parts and ensure the movement speed of the whole machine.
Tags: laser cutting machine for steel, fiber sheet cutting machine, laser cutting machine for stainless steel.
Application
1. Applicable materials
The fiber sheet cutting machine is widely suitable for 3D cutting of all kinds of metals, such as: stainless steel, carbon steel, aluminum alloy, silicon steel, brass, copper, galvanized sheet, etc.
2. Applicable industries
the fiber sheet cutting machine is widely used in the automotive industry for cutting such as: cutting prototype parts, body panel cutting, trimming, cutting steering wheel holes, body windshield, roof cover bracket holes, airbag components, hydraulic molded parts.
3D laser cutting is also useful in the assembling of the body, such as the top cover rail hole, the antenna mounting hole, the shape of the wheel fender, etc.
In addition, the laser cutting machine for stainless steel is also widely used in many industries, such as: molds, medical equipment cutting, hardware products, kitchen ware, home decoration, advertising field, manufacturing industries.
Technical Data
Product Name |
Fiber Sheet Cutting Machine |
Model |
PE-F2030G |
Laser Source |
World Famous Brand Fiber Laser Source (Raycus / Max / IPG) |
Laser Power |
500w / 1000w / 1500w / 2000w / 3000w |
Cutting Thickness |
500w: 4-6mm Carbon Steel 1000w: 7-10mm Carbon Steel 1500w: 10-15mm Carbon Steel 2000w: 15-20mm Carbon Steel 3000w: 18-22mm Carbon Steel (According to Different Laser Power and Materials) |
Maximum Idle Speed |
100m/min |
Minimum Line Width |
0.15mm |
Positioning Accuracy |
±0.07mm |
Repeat Positioning Accuracy |
±0.04mm |
Work Arm Display |
1400mm-2030mm |
Working Area |
≤4000mm-2000mm |
Power Configuration |
AC 380V±10%50Hz |
Cooling Method |
Water Cooling |
Protection Level |
IP45 |
Guarantee |
2 Years Guarantee for Fiber Laser Source 12 Month Guarantee for Fiber Sheet Cutting Machine |
Training |
VCD Training Video for Easy Learning Engineer Overseas Installation & Training is Available |
