Fire Pull Station Fire Manual Call Point Wireless Fire Alarm System

Fire pull station fire manual call points are installed on every floors entrance places. The siren strobe sound light alarm can be directly triggered by the manual call point alarm. Wireless fire alarm system is easy to installed even with non-professional persons.

wireless manual call point is suitable for installation in public places, factories and other environments. When a fire is manually confirmed, press the button, and the red light of the MCP is always on, so that an alarm signal can be sent

to the control panel through wireless communication technology. When the control panel responds to the alarm signal, the MCP enters a state of waiting for the control panel to reset, and the control panel displays the coded information of the MCP and gives an alarm sound.

Technical Data:

All data is supplied subject to change without notice.

Specifications are typical at 24V, 25℃ and 50% RH unless otherwise stated.

Battery CR17450 3V Voltage range 2.7~3.3V

Operating current monitoring current≤10uA , alarm current≤19mA

Coding method automatically assigned when networking

Radio frequency transmit power<20dBm

Frequency band 470MHz

Operating environment temperature 10℃~+55℃ relative humidity ≤95%

Dimension 95mm*96mm*50mm

Weight 190g

Push-type structure design is adopted, and special tools are required to reset after pressing MCP;

Using 470MHz wireless communication technology, there is no need to embed wiring, and the engineering installation is convenient and fast; with battery low voltage detection function, which can reflect the battery power situation

in time; Using microprocessor to realize signal processing, communicating with controller by digital signal, it works stably and reliably, and has good ability to suppress electromagnetic interference.
