Network Transformer Automatic Winding Machine
Network transformer automatic winding machine is used in the electronic components industry to provide solutions for the production of network transformer 4532, 5365, 6553, 3532 and other series of products. The equipment can be tailor-made for customers, designed and developed based on the characteristics of assembly and production processes to meet customers' product design and processing needs and efficiency needs. Tooling profiling design, and full use of various high-precision sensors to achieve the effect of foolproofing and error-proofing. This equipment mainly completes the loading, winding, press welding and unloading processes of the magnetic core skeleton.
Product Details
Advantages
01 3-axis manipulator adopts servo motor + screw + guide rail structure.
02 The winding mechanism reserves an installation position for the single- and double-wire switching function.
03 The clamp will not cause the magnetic core to be crushed or cracked.
04 Winding stations are equipped with a cutter and wire cutting function, and the wire cutting position is adjustable.
05 The waste wire unload mechanism at the winding point absorbs the waste wire through vacuum.
06 The wire are neatly arranged without overlapping or crossing, and the insulation paint of the wire is intact.
Equipment Parameters
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
