6kw marine silent diesel generator seawater-cooled

Name: 6kw marine silent diesel generator seawater-cooled
Availability: InStock

FOB Price

US$ 18200 - 19200 / Set

5 Sets(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Description

6kw marine silent diesel generator seawater-cooled

Model No.				8000STD
Generator Set	Rated Frequency		HZ	50	60
	Prime Power		KVA	5.5	6.5
			KW	5.5	6.5
	Standby Power		KVA	6	7
			KW	6	7
	Rated Voltage		V	115/230	120/240
	Rated Current		A	47.8/23.9	56.5/28.3
	Rated Speed		r/min	3000	3600
	Control Panel			Smartgen 4010 Display
	Output	Socket		No
		Terminal		Yes
	Noise（ at 7m）		dB(A)	58
	Machine Size		mm	700×500×560
	Machine Weight		kg	150
Alternator	Alternator Model			YP8000STD
	Number of Poles			4
	Phase			Single
	Excitation Method			Brushing self excitation constant voltage (With AVR)
	Power Factor		COSΦ	1
	Insulation level			F
Diesel Engine	Model			YDM80S
	Engine Type			Single cylinder inline, four stroke, direct injection, water-cooled
	Bore×Stroke		mm	92×75
	Displacement		L	0.499
	Compression Ratio			19.5∶1
	Rated Power		KW	7.6	8.6
	Cooling water volume(engine only)		L	4
	Lubrication method			Pressure Splash Composite
	Oil No.			CD grade or above，SAE 10W-30、15W-40
	Oil Tank Volume		L	1.65
	Start Method			12V Electric
	Volume of Start Alternator		V-KW	12V 1.2KW
	Fuel Consumption		g/KW.h	298
	Fuel No.			Diesel： 0＃（Summer）-10＃（Winter）-35＃（Severe cold）
