Meichao Cursor Auto Alignment Curved Screen Printing Machine Suit For Coffee Cup And Milk Tea Cup Bottle Tub And Pen

Product name : Curved screen printing machine cursor automatic positioning

I. Introduction of the machine

This is a high-precision circular surface servo cursor alignment screen printing machine, running fast, stable performance, can be formed in a small factory space screen printing production line, especially suitable for printing high precision circular products, and no positioning point need to color circular products. Left and right servo rotation servo up and down electric control, printing only need to input parameters to achieve the required printing data, accurate to two decimal places that is 0.01MM.

(1). Touch screen human-machine interface with programmable controller, adjustment does not rely on experience but data

(2). Full touch screen man-machine dialogue control mode, easier to adjust the machine, fingertip control can meet the printing needs

(3). Automatic four-digit counter to count the number of prints.

(4). Double column lifting structure, stable and high precision.

(5). Left and right travel data control.

(6). Printing action design a variety of printing cycles, users can freely choose the printing process.

(7). The position of the net frame can be adjusted before and after, around, level and height.

(8). Scraper constant pressure device to ensure stable pressure in the printing process

(9). The machine running speed is fast and stable.

2. Technical parameters

Printing surface: cylinder surface

Printing color: can be colorful printing

Operating voltage: 220V 50-60mhz /100W

Compressed air pressure: 0.5-0.7MPA

1, starting mode: panel/foot switch

2, scraper pressure control: pressure regulator constant pressure

3, up and down drive mode: Toth motor

4, left and right drive mode: Huichuan servo

5, rotary drive mode: Huichuan servo

6, left and right stroke: 550MM

7, up and down stroke: 100MM

8, the maximum screen size: 300*550MM

9, the maximum product diameter: 100MM

10, maximum product printing length: 300MM

11, Alignment accuracy<0.02MM

12, color code color detection automatic alignment.

13. Machine weight: 190KG

14, machine size: 80*97*130cm

15, power: 1000W

16, machine speed: 1500
