Multifunctional Mobile High and Low Temperature Experimental Quenching Tank,hardening Tank
US$ 200 - 8000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
ChengChi
Place of Origin:
China
Model Number:
QT05
Payment & Shipping
Payment Methods:
Port of Shipment:
ShangHai
Delivery Detail:
35 days
Related Products
-
Belt Lifting Continuous Automatic Quenching Tank,quenching Tank,hardening Tank,continuous Quenching TankUS$ 200 - 8000MOQ: 1 Set -
Quenching Brine Tank,hardening Tank,oil Quenching Tank,water Quenching Tank,quenching Salt Tank,quenching Alkali Tank,corrosion-resistant Quenching TankUS$ 200 - 8000MOQ: 1 Set
-
China Multifunctional Automatic Quenching Tank,quenching Tank,hardening Tank,continuous Quenching TankUS$ 200 - 8000MOQ: 1 Set
-
Fully Automatic Small Mobile Quenching Water Tank,water Quenching Tank,quenching Tank,water Hardening Tank,automatic Water Quenching TankUS$ 200 - 8000MOQ: 1 Set
-
Chengchi Brand EYQT Laboratory Swing Quenching TankUS$ 200 - 8000MOQ: 1 Set
Brand Name
ChengChi
Place of Origin
China
Model Number
QT05
Type
Control Box
External Size
Tailor-made
Protection Level
IP54
Multifunctional mobile high and low temperature experimental quenching tank,hardening tank
The multifunctional mobile high and low temperature experimental quenching tank,hardening tank is a new type of functional quenching developed for the experimental process according to the special requirements of the experimental process, especially for the wide range of quenching medium temperature requirements (low temperature ≤20 ℃, high temperature ≥60 ℃) groove.
The quenching tank body is made of profile steel as the skeleton, and the steel plates are closely welded. Special models are lined with aluminum silicate ceramic fiber insulation. The quenching tank mainly consists of tank body, circulation system, stirring system, cooling system, heating system (auxiliary heat), lifting system, safety system, control system, etc. Special functions can be customized according to the needs of each customer.
Mobile high and low temperature experimental quenching tank
Low-temperature quenching requirements, for example, the optimal quenching liquid temperature is 25 ℃. In summer, because the ambient temperature is high, it is easy to cause the quenching liquid coolant temperature to be high, which is difficult to produce a better cooling effect. Especially in summer, as the room temperature is higher and the quenching temperature is lower than room temperature -10 ℃, it is difficult to achieve the temperature requirement through conventional air cooling. If the cooling tower is equipped, it will be too large and the pipeline needs to be laid. Inconvenience and other disadvantages. Chengchi's mobile experimental high and low temperature quenching tank for R & D and production has the advantages of small size, full function, high integration, wide temperature range, energy saving, high degree of automation, and convenient movement.
