LOCTITE 315

Technology:Acrylic

Chemical Type:Acrylic

Appearance (uncured):Blue paste

Components:One component - requires no mixing

Viscosity:High

Cure:Activator

Application:Bonding

Henkel LOCTITE 315 300ML is a self-shimming thermally conductive, one part adhesive for bonding electrical components to heat sinks with an insulating gap.

The high thermal conductivity provides excellent heat dissipation for thermally sensitive components, while the controlled strength permits field and service repair.

The self-shimming property produces a consistent 5-6 mil gap between the component and the heat sink.

This gap results in electrical insulation while maintaining thermal conductivity.

Typical applications include bonding transformers, transistors and other heat generating electronic components to printed circuit board assemblies or heat sinks.

In high pot applications this product should be limited to a maximum of 500 volts. Activator 7387 is required for proper curing of Loctite  Output adhesives.
