MATERIAL DESCRIPTION
Hastelloy N (UNS N10003) is a nickel based alloy which as a container material for molten fluoride salts. It has good oxidation resistance to hot fluoride salts in the temperature range of 704-871ºC.
Hastelloy N Specifications:
| Trademark | GB | GOST | ASTM | UNS |
| Hastelloy N | - | - | Hastelloy N | N10003 |
Hastelloy N Product Forms and Standards:
| Rod, Bar, Wire and Forgings | ASTM B573, ASME SB573, AMS 5771 |
| Plate, Sheet and Strip | AMS 5607, ASTM B434, ASME SB434 |
| Pipe and Tube | - |
| Welding Product | ERNiMo-2 A5.14 |
| Others | ASTM B366, ASME SB366 |
HASTELLOY S alloy (UNS N06635) is a nickel-base, high-temperature alloy with a unique combination of properties. It has excellent thermal stability, low thermal expansion and excellent oxidation resistance to 2000°F (1093°C). In addition, the alloy has good high-temperature and thermal fatigue strength. S alloy retains its strength and ductility after aging at temperatures of 800 to 1600°F (427 to 871°C).
S alloy was developed for applications involving severely cyclical heating conditions where components must be capable of retaining their strength, ductility, and metallurgical integrity after long-time exposure. It is used extensively as seal rings in gas turbine engines where its low thermal expansion coefficients is also important.
Hastelloy W alloy (UNS N10004) is a solid-solution-strengthened super alloy that was developed primarily as a filler metal for welding of dissimilar alloys. It displays excellent dissimilar welding characteristics, and is widely used for that purpose in the gas turbine and aerospace industries. The properties of dissimilar weld joints made with alloy W are dependents upon the alloys joined, but are generally acceptable for a wide variety of combinations. Alloy W is also used as a wrought alloy for a limited number of ring-type Applications in older gas turbine engines. Haynes 242 alloy is a more modern alloy, and should be considered as a substitute for alloy W in these ring Applications.
Hastelloy W Specifications:
| UNS | W. Nr | DIN |
| N10004 |
The Hastelloy X nickel alloy, with higher iron content, has favorable resistance to oxidation and corrosion combined with excellent creep and rupture strength at temperatures under 900ºC. In addition to this, Hastelloy alloy X has great fabricability by cold and hot working and good weldability.
High degree of oxidation resistance up to 2200° F
Outstanding high-temperature strength
Easily fabricated including forming and welding
Good ductility after prolonged exposure at high-temperatures
Good resistance to chloride stress-corrosion cracking
Resistant to carburization and nitriding
Develops a protective oxide film that does not spall off
| UNS | W. Nr |
| N06602 | 2.4665 |
Hastelloy X Product Forms and Standards:
| Bar | Sheet/Strip | Wire | Pipe |
| ASTM B572 | ASTM B435 | ASTM B166 |
ASTM B622 ASTM B619 ASTM B626 |
CHEMICAL COMPOSITION
Hastelloy N Chemical Compositions:
| Alloy | C | Si | Mn | P | S | Cr | Ni | Mo | W | Al+Ti | Cu | B | V | Fe |
| Hastelloy N | 0.04-0.08 | ≤1.00 | ≤1.00 | ≤0.025 | ≤0.010 | 6.0-8.0 | Bal | 15.0-18.0 | ≤0.50 | ≤0.50 | ≤0.35 | ≤0.01 | ≤0.50 | ≤5. |
Hastelloy S Chemical Compositions:
| Elements | Content (%) |
| Nickel, Ni | 67 |
| Chromium, Cr | 14.5 - 17 |
| Molybdenum, Mo | 14 - 16.5 |
| Iron, Fe | 3 |
| Cobalt, Co | 2 |
| Tungsten, W | 1 |
| Copper, Cu | 0.35 |
| Manganese, Mn | 0.30 - 1.0 |
| Silicon, Si | 0.20 - 0.75 |
| Aluminum, Al | 0.10 - 0.50 |
| Carbon, C | 0.020 |
| Phosphorous, P | 0.020 |
| Boron, B | 0.015 |
| Sulfur, S | 0.015 |
| Lanthanum, La | 0.010 - 0.10 |
Hastelloy W Chemical Compositions:
| Alloy | C | Si | Mn | P | S | Cr | Ni | Co | Mo | W | V | Fe |
| Hastelloy W | ≤0.12 | ≤1.00 | ≤1.00 | ≤0.04 | ≤0.03 | 4.0-6.0 | Bal | ≤2.5 | 23.0-26.0 | ≤1.00 | ≤0.06 | 4.0-7.0 |
Hastelloy X Chemical Compositions:
| Composition | Ni | Cr | Fe | Mo | W | Co | C | Mn | Si | S | Cu | Al | Ti | |
| Content (%) | Min. | Bal. | 20.5 | 17.0 | 8.0 | 0.2 | 0.5 | 0.05 | ||||||
| Max. | 23.0 | 20.0 | 10.0 | 1.0 | 2.5 | 0.15 | 1.0 | 1.0 | 0.015 | 0.5 | 0.15 | 0.5 | ||
MECHANICAL PROPERTIES
Hastelloy N Mechanical Properties (RT, Annealed)
| Density, g/cm3 | Melting Point, ºC | Tensile Strength, MPa | Yield Strength, MPa | ELongation, % | Hardness, HRB |
| 8.86 | 1300-1400 | 462 | 148 | 47 | / |
Hastelloy W Mechanical Properties (RT, Annealed)
| Density, g/cm3 | Melting Point, ºC | Tensile Strength, MPa | Yield Strength, MPa | ELongation, % | Hardness, HRB |
| 9.00 | 1290-1375 | 965 | 520 | 51 | / |
Hastelloy X Mechanical Properties (RT, Annealed)
| Tensile Strength (σb/MPa) | Yield Strength (σp0.2/MPa) | Elongation (σ5/%) |
| 690 | 275 | 30 |
APPLICATION
Hastelloy N Applications:
Hastelloy N is used in chemical process equipment and general industrial applications requiring high temperature oxidation resistance.
Hastelloy W Applications:
Hastelloy W is widely used for that purpose in gas turbines, aerospace and chemical process industries.
Hastelloy X Applications:
This oxidation resistant alloy can be used for combustor components and other high temperature parts of aircraft engines, for long term use at temperature under 900ºC and short time use up to 1080ºC.
Gas turbine engines
Transition ducts
Combustor cans
Spray bars and flame holders
Afterburners, tailpipes, and cabin heaters
Chemical processing retorts, muffles, and tubing
