Home > Products > GNSS antennas > RTK High Precision UAV Antenna 3 Star 7 Frequency Four-Arm Spiral Antenna Waterproof and Anti-jamming 25g Diameter
RTK High Precision UAV Antenna 3 Star 7 Frequency Four-Arm Spiral Antenna Waterproof and Anti-jamming 25g Diameter
US$ 85 - 95
/ Piece
10 Pieces(Min. Order)
- shenzhen
- T/T
- 30 days
You May Like
-
Shenzhen Jinwen JWGPS1840 Active Built-in GPS Antenna 18*18*4mm
-
RTK High Precision GPS /B1/B2/B3/GLONASS Samsung Octa-Band Measurement Active Antenna
-
Jinwen GPS Amplifier GNSS Signal Amplification Low Noise for Stations, Basements, Bridges
-
Jinwen 4G FDD LTE1800MHZ (bAND3) Integrated RF Microwave Power Amplifier Electronic Fence System
-
Shenzhen Jinwen Active Beidou GPS Antenna Has Low Noise and High Rejection 20X6X4mm
-
Shenzhen Jinwen GPS Antenna JW2520B High Precision and High Stability 25*25*2mm
Product Details
| Trademark | jinwen | Origin | china |
Product Description
Product Name: Four-arm spiral active antenna
Applicable frequency bands: B1, GPS, GLONASS
1. The antenna gain is high, the beam width is 3dB, and the built-in filter can ensure that the received signal is far away and not interfered by other signals.
2. Low noise amplification circuit, which can effectively improve the signal-to-noise ratio of the system.
3. The energy of the antenna is strong all around, which can effectively improve the receiving space range of the antenna.
4. The product has a wide frequency band and built-in lightning protection device.
Frequency range (MHz) 1207-1268/1561-1602
Antenna gain (dBi) 3
LNA gain (dB) 35
VSWR: ≤1.5
Noise figure ≤ 1.5: ≤1.5
Polarization: Right-handed circular polarization
Axial ratio (dB) ≤2
DC power supply(V) 3.5-18V
Output Impedance (Ω) 50
Operating current (mA) ≤80
3dB beamwidth (°) 80
Connector form SMA-K
Operating temperature(°C) -40~+70
Storage temperature (°C) -55~+70
