316H Stainless Steel Tube
- 9999 Ton / Tons per Month
- T/T L/C
Product Description
Name: 316H Stainless Steel Tube
Size: 1/2" NB - 24" NB
Material: 316H
Type:square, round, rectangle, hydraulic
Thickness range: 0.40 mm - 12.70 mm
Surface Treatment: Polishing, Hairline, Pickled, etc.
Finished condition: Round, Square, Rectangular, Coil,U Tube
Application: Petrochemical, Oil & Gas; Geothermal, Mining;Chemical Process, Pharmaceutical, Biomass;Sea Water, Water Desalination; LNG (Liquefied Natural Gas), Nuclear Power, Solar Power。
Model number:
Orignal: Wenzhou,Zhejiang
Standrad:ASTM A213/ ASTM SA213
Brand:
Technics:
Package: Packed in woven bag, or put in wooden case
Price:
Delivery: Accord Quantity
Certificate:
Production ability:
Product Detail
Stainless steel 316H seamless tubes are the most popular and widely used products that are used for different industrial as well as domestic applications. These seamless tubes are manufactured using top-notch quality of raw material and latest machines that are used by skill experts.
The producers are aimed to produce the accurate length and size of tubes that can easily fulfill all the demands and requirement of customers worldwide. These tubes are known for their exceptional features and properties which makes them even more popular.
Table of Content:
1. Specification of 316H Stainless Steel Tube
2. Applications of 316H Stainless Steel Tube
3. Chemical Composition of 316H Stainless Steel Tube
4. Mechanical Properties of 316H Stainless Steel Tube
5. Grade Specifications of 316H Stainless Steel Tube
6. Physical Properties of 316H Stainless Steel Tube
7. Types Of Stainless Steel 316H Pipes Tubes
8. 316H Stainless Steel Tube Price List
Specification of 316H Stainless Steel Tube
Standard | ASTM A269, ASTM A213, ASTM A312, ASME SA269, ASME SA213, ASME SA312 |
Grade | 202, 304, 304L, 304H, 304LN, 309S, 310S, 316, 316L, 316H, 316Ti, 316LN, 317L, 321, 321H, 347, 347H, 904L, SMO 254, ALLOY 254, 6MO, 6MOLY, UNS S31254 ETC. |
Type | Seamless / Welded / ERW / EFW / Cold Draw / Hot Finish / Cold Finish |
Length | 01 Meter to 12.5 Meters, Single Random Length, Double Random Length And Customize Size |
End | Plain Ends / Beveled Ends |
Applications of 316H Stainless Steel Tube
l Food preparation equipment particularly in chloride environments.
l Laboratory benches & equipment.
l Coastal architectural panelling, railings & trim.
l Boat fittings.
l Chemical containers, including for transport.
l Heat Exchangers.
l Woven or welded screens for mining, quarrying & water filtration.
l Threaded fasteners.
l Springs.
Chemical Composition of 316H Stainless Steel TubeSS | 316H |
Ni | 10 - 14 |
N | 0.10 max |
Cr | 16 – 18 |
C | 0.04 - 0.10 |
Si | 0.75 max |
Mn | 2 max |
P | 0.045 max |
S | 0.030 max |
Mo | 2.00 - 3.00 |
Mechanical Properties of 316H Stainless Steel Tube
Grade | 316H |
Tensile Strength (MPa) min | 515 |
Yield Strength 0.2% Proof (MPa) min | 205 |
Elongation (% in 50mm) min | 40 |
Hardness | |
Rockwell B (HR B) max | 95 |
Brinell (HB) max | 217 |
Grade Specifications of 316H Stainless Steel Tube
Grade | UNS No | Old British | Euronorm | Swedish SS | Japanese JIS | ||
BS | En | No | Name | ||||
316H | S31609 | 316S51 | - | - | - | - | - |
Physical Properties of 316H Stainless Steel Tube
Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (m/m/0C) | Thermal Conductivity (W/m.K) | Specific Heat 0-1000C (J/kg.K) | Electrical Resistivity (n.m) | |||
0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
316H | 8000 | 193 | 15.9 | 16.2 | 17.5 | 16.3 | 21.5 | 500 | 740 |
Types Of Stainless Steel 316H Pipes Tubes
Stainless Steel 316H Tubes
Stainless Steel 316H tubes
ASTM A269 TP 316H stainless steel seamless tubes
AISI 316H seamless Tubing in Iran
ASTM A213 TP 316H stainless steel seamless tubes
AISI 316H welded tubes
AISI 316H ERW Tubing in Dealer Singapore
SS 316H tubes Exporter in Bahrain
ASTM A249 TP 316H stainless steel welded tubes
