Atmosphere Furnace shanghai factory

Product Overview

Box atmosphere furnace furnace adopts imported high-purity alumina ceramic fiber thermal insulation material, which has characteristics of good thermal insulation effect, durability, balanced temperature field, and no pollution. The temperature control system adopts industrial precision 0.2 level intelligent instruments, with accurate temperature control, no temperature surge, and convenient operation. By pre vacuuming to ensure that the oxygen content in the furnace is reduced to a very low level, and then filling in inert gases such as nitrogen to repeatedly flush the furnace several times, the equipment achieves better heat treatment results with atmosphere protection

Product Usage

It is mainly used in the R&D and experimental processes of metal materials, ceramic materials, semiconductor materials, and small batch production of materials such as silicon carbide

General dimensions of equipment

Wide x High x Deep

100X100X100mm

150x150x200mm

200x200x300mm

300x300x400mm

500x500x500mm

600x600x600mm

......

or customized it as your require.（choose one)

Max. temperature: 1200 /1400 /1700 （choose one)

chamber material: Alumina ceramic fiber OR lightweight bricks （choose one)

Vacuum: -0.8Mpa

support gas: inert gas

PLEASE let me know your choose and special require.
