Help Center1600c Inert Gas , Argon, Nitrogen Atmosphere Ceramic Sintering Furnace / Atmosphere Furnace
Related Products
-
High Temperature Metal Ceramic Sintering FurnaceUS$ 1,500 - 5,000MOQ: 1 Set -
YIFAN Automatic Heat Treatment Furnace for Annealing/quenching/hardening/tempering YF-1700BLUS$ 1,500 - 5,000MOQ: 1 Set
-
YIFAN China Famous OEM/ODM Manufacturer Cad Cam Dental Zirconia Sintering FurnaceUS$ 800 - 2,000MOQ: 1 Set
-
YIFAN EXW Price High Quality Horizontal Type High Temperature Mini Muffle Furnace Used Heating and Sintering 1700CUS$ 800 - 2,000MOQ: 1 Set
-
YIFAN Fritting Furnace 1200CUS$ 800 - 2,000MOQ: 1 Set
biobase laboratory equipment
Features for lab vacuum bottom load furnace :
The furnaces can protect materials from oxidation and decarburization with flowing Nitrogen,Argon and other inert gas,balanced temperature field,fast temperature rising and cooling,energy-efficient,delicate appearance,practical.
also can work under vacuum up to -0.1Mpa
It is widely used for sintering,reducing with inert atmosphere in labs of colleges and universities,research institutes and industrial and mining enterprise.
Our products have the advantages warming faster 20-40 mins, energy saving, high precision temperature control, heat preservation performance , the microcomputer control, programmable automatic temperature, temperature at furnace wall to such high interest conditions, Widely used in ceramic industry, chemical industry, electronic, metallurgy, new materials, machinery, fire-proof material, building materials, special materials of experiment and production. welcome old and new customers.
Double layers steel casing with fan cooling, to ensure the surface of furnace below 50 °C.
Lifting bottom controlled by electric, freely lift or down.
Up and down limited switch, double safety for bottom moving.
1. Operation Temperature: 1700°C/1600°C.
2. Maximum energy efficiency is achieved by surrounding the chamber with thermal-efficient alumina fiber ceramic insulation.
3. Heavy duty double layer structure with cooling fan. Lower teperature in outside case.
4. PID automatic control via current limiting phase angle fired the resistor, e.g. SCR(Silicon Controlled Rectifier).
5. Power control with 30 segments programmable.
We offer OEM service for you!
1.Directly manufacturer offering the best price and quality and service.
2.One sales will be serves client from inquiry to products delivery .Communicate directly and conveniently.
3.Professional R&D team.
4.Strict QC.
5,Professional packing and shipping.ensure goods arrived safely
6.Offering OEM /ODM services.Our AGENT customers are all over the world like USA, UK, Russia, Korea, Southeast Asia, etc. we are quite experienced to help client win more market.
7.Certificate: All our products are CE approval.
8.Fast reply: Our team will respond your requests within 8working-hours
| Model: | YFA-1700BL |
| Main Specifications: | |
| Inside Chamber Size | Dia120/80mm |
| Standard Working Temperature | 1600oC ( continuous ) |
| Maximum Working Temperature | 1700oC ( < 3 hrs) |
| Furnace Atmosphere | Nitrogen, Argon and other inert gases |
| Vacuum degree: | .- 0.1MPA |
| Temperature Control | 30 steps programmable and PID automatic control |
| Heating Rate | 0~ 40.C/ min (suggestion: =< 20.C ) |
| Temperature Accuracy | +/- 1 .C |
| Furnace structure | Double shell with fan cooling |
| Heating Element | MoSi2 heating elements |
| Thermocouple | B type |
| Working Voltage | AC 220V Single Phases 60/50 Hz (or according to your requirement) |
| Max. Power | 2KW |
| Outside Size | 550 x 540 x 820 mm |
| Net Weight | 70 Kg |
| YFA series box atmosphere furnace can protect materials from oxidation and decarburization with flowing Nitrogen, Argon and other Inert gas. It’s an ideal furnace for sintering, reducing with inert-atmosphere in labs of university, Research Institution and industrial company. | |
| Standard package included with the furnace | |
| Part description | Quantity |
| Thermal couple | 1 pc |
| Inlet/outlet,valves | 1 set |
| Flow meter | 1 pc |
| Vacuum gauge | 1 pc |
| Vacuum pump | 1 pc |
| Furnace door block | 1 pc |
| Thermal gloves | 1 pair |
| Operation manual | 1 pc |
Standard size for refer:
| Model | Square Chamber size(WxHxDmm) | Round chamber size (DIAxHmm) |
| YFA-1700BL | 120x120x130mm | 120/80mm |
| YFA-1700BL | 150x150x150mm | 150/100mm |
| YFA-1700BL | 200x200x200mm | 200/180mm |
| YFA-1700BL | 200x200x300mm | 200/300mm |
| YFA-1700BL | 250x250x300mm | 250/300mm |
| YFA-1700BL | 300x300x400mm | 300/400mm |
| YFA-1700BL | 450x450x500mm | 450/500mm |
| YFA-1700BL | 600x600x600mm | 600/600mm |
A:AI - 808P artificial intelligence temperature controller, temperature
control system using artificial intelligence technology, with a PID regulator, fuzzy control, autotuning function, and can prepare the 50 - segment heating and cooling procedures
B:PLC 50 segment touch screen controller with recorder ,internet connect,data ouput ,compute control function.
New type industrial-grade touch screen operation,all the parameter set in one interface easily , the client can be used as the use of mobile phones easily,New AI artificial intelligence logic PID algorithm ,data record function,support customzied meue.
Package: Plastic paper inside, Polyfoam filled, Wooden box outside.
Payment: L/C T/T, West union,etc.
Shipping and Delivery: by air or sea , in 15 days after receiving the payment
Warranty:Our products are warranted to be free from defects in materials or workmanship for one year from the date of purchase. Within this period, Across International will, at its sole options, replace any components that fail in normal use. Such replacement will be made at no charge to the customer for parts, provided that the customer shall be responsible for any transportation cost. This warranty does not cover consumables and failures due to abuse, misuse, accident or unauthorized alteration or repairs.
Replacement will be shipped to you after photo or other evidence are provided and investigated.
