1、Introduction：
Part of the SmartLine® family of products, the STA800 and STA80L are high performance absolute pressure transmitters featuring piezoresistive sensor technology combining pressure sensing with on chip temperature compensation capabilities providing high accuracy, stability and performance over a wide range of application pressures and temperatures. The SmartLine family is also fully tested and compliant with Experion® PKS providing the highest level of compatibility assurance and integration capabilities. SmartLine easily meets the most demanding application needs for pressure measurement applications.
2、Best in Class Features:
• Accuracies up to 0.0375% of span standard & 0.025% of span optional
• Stability up to 0.01% of URL per year for 15 years
• Automatic temperature compensation
• Rangeability up to 100:1
• Response times as fast as 80ms
• Multiple local display capabilities
• External zero, span, & configuration capability
• Polarity insensitive electrical connections
• Comprehensive on-board diagnostic capabilities
• Integral Dual Seal design for highest safety based on ANSI/NFPA 70-202 and ANSI/ISA 12.27.2
• Full compliance to SIL 2/3 requirements
• Modular design characteristics
• Available with additional 15-year warranty
• Plugged Impulse Line Detection Option
• Dual/Triple Calibration Option (HART & Fieldbus Only)
3、Communications/Output Options:
• 4-20mA
• Honeywell Digitally Enhanced (DE)
• HART ® (version 7.0)
• FOUNDATION™ Fieldbus
All transmitters are available with the above listed communications protocols.
4、Span & Range Limits:
Model |
URL mmHgA (mbarA) |
LRL mmHgA (mbarA) |
Min Span mm HgA (mbarA) |
STA822/82L |
780 (1040) |
0 (0) |
50 (66.7) |
Model |
Psia (barA) |
psi (barA) |
psi (barA) |
STA840/84L |
500 (35) |
0 (0) |
5 (.35) |
STA87L |
3000 (210) |
0 (0) |
30 (2.1) |
