1、Introduction：
Part of the SmartLine® family of products, the STD800 is a high performance differential pressure transmitter featuring piezoresistive sensor technology. By combining differential pressure sensing with on chip static pressure and temperature compensation the STD800 offers high accuracy and stability over a wide range of application pressures and temperatures. The SmartLine family is also fully tested and compliant with Experion ® PKS providing the highest level of compatibility assurance and integration capabilities. SmartLine easily meets the most demanding application needs for pressure measurement applications.
2、Best in Class Features:
• Accuracies up to 0.035% of span standard & 0.025% of span optional
• Stability up to 0.01% of URL per year for 15 years
• Automatic static pressure & temperature compensation
• Rangeability up to 400:1
• Response times as fast as 90ms
• Multiple local display capabilities
• External zero, span, & configuration capability
• Polarity insensitive electrical connections
• Comprehensive on-board diagnostic capabilities
• Integral Dual Seal design for highest safety based on ANSI/NFPA 70-202 and ANSI/ISA 12.27.0
• World class overpressure protection
• Full compliance to SIL 2/3 requirements.
• Modular design characteristics
• Available with additional 15-year warranty
• Plugged Impulse Line Detection Option
• Dual/Triple Calibration Option (HART & Fieldbus only)
3、Communications/Output Options:
• 4-20mA
• Honeywell Digitally Enhanced (DE)
• HART ® (version 7.0)
• FOUNDATION™ Fieldbus
All transmitters are available with the above listed communications protocols.
4、Span & Range Limits:
Model |
URL inH2O (mbar) |
LRL inH2O (mbar) |
Min Span inH2O (mbar) |
STD810 |
10 (25) |
-10 (-25) |
0.1 (0.25) |
STD820 |
400 (1000) |
-400 (-1000) |
1.0 (2.5) |
Model |
psi (bar) |
psi (bar) |
psi (bar) |
STD830 |
100 (7.0) |
-100 (-7.0) |
1 (0.07) |
STD870 |
3000 (210) |
-100 (-7.0) |
30 (2.1) |
5、About us
Chengdu Shengzhijie Technology Co., Ltd. is a high-tech enterprise mainly engaged in the business of internationally renowned advanced process control and automation products. It is committed to the sales, engineering, testing, maintenance, technical training and service of industrial control products and control systems. The products involve the main products related to automation, such as: Distributed control system (DCS)/Programmable logic controller (PLC), Instrument Safety system (SIS), data acquisition system (SCADA), process controller, recorder, pressure and temperature transmitter (sensor), dangerous gas detection and alarm, gas flow measurement, combustion safety control, valve and actuator, detection and analysis instrument, signal adjustment Management module, is the United States Honeywell control products in western China's largest level agents and inventory center, the United States Honeywell DCS, PLC and SIS control system core engineering, at the same time distribution of the United States Acromag, the United States capital company, the United States lion fine instrument company and other world famous brand products.
We look forward to establishing long-term business relationship with you!
