1、Introduction：
Part of the SmartLine® family of products, the STF700 is a flange mounted level transmitter suitable for monitoring, control and data acquisition featuring piezoresistive sensor technology. STF700 transmitters may be directly mounted onto a tank flange and are offered with a variety of tank connections including various flush and extended diaphragm configurations. STF700 offers high accuracy and stability over a wide range of level applications. The SmartLine family is also fully tested and compliant with Experion ® PKS providing the highest level of compatibility assurance and integration capabilities. SmartLine easily meets the most demanding application needs for pressure measurement applications.
2、Best in Class Features:
• Accuracies up to 0.05% of span standard & 0.04% of span optional
• Stability up to 0.020% of URL per year for 10 years
• Automatic static pressure & temperature compensation
• Rangeability up to 100:1
• Response times as fast as 100ms
• Easy to use and intuitive display capabilities
• Intuitive External zero, span, & configuration capability
• Comprehensive on-board diagnostic capabilities
• Integral Dual Seal design for highest safety based on ANSI/NFPA 70-202 and ANSI/ISA 12.27.0
• World class overpressure protection
• Full compliance to SIL 2/3 requirements.
• Modular design characteristics
• Available with additional 4-year warranty
3、Communications/Output Options:
• HART ® (version 7.0)
4、Span & Range Limits:
Model |
URL inH2O (mbar) |
LRL inH2O (mbar) |
Min Span inH2O (mbar) |
STF725 |
400 (1000) |
-400 (-1000) |
4.0 (10.0) |
STF72P |
400 (1000) |
-400 (-1000) |
4.0 (10.0) |
Model |
psi (bar) |
psi (bar) |
psi (bar) |
STF735 |
100 (7.0) |
-100 (-7.0) |
1 (0.07) |
STF73P |
100 (7.0) |
-100 (-7.0) |
1 (0.07) |
