German Technical Background VOK-UV 3530 Surface Additives Suitable for Water-based Radiation Curing Printing Ink and Varnish Replaces BYK-UV 3530

German technical background VOK ®- Surfactant for UV 3530 radiation curing system (silicone surfactant)

VOK ®- UV 3530 is a silicone surfactant used for waterborne radiation curing printing ink and varnish. Strongly reduce surface tension and good substrate wettability. It can also improve the leveling property of 100% UV system, without affecting the smoothness.

Product Information

Chemical composition

Polyether containing acrylate functional group modified polydimethylsiloxane.

Typical Physicochemical Data

The data given in this data page are only typical values, not technical indicators of the product.

Density (20 ° C): 1.08 g/ml

Refractive index (20 ° C): 1.460

Effective ingredients: 100%

Storage and transportation

Storage and transportation below 40 ° C.

Special reminder

VOK ®- UV3510 may appear turbid and gray, which does not affect the application effect of the product. Field of application Printing ink and varnish

Features and Benefits

VOK ®- UV3530 is an organic silicon surfactant that will gather at the film/substrate interface in the waterborne radiation curing system. Its acrylate functional group enables it to be cross-linked into the polymer network, so it can be permanently fixed on the interface, thus preventing the migration of silicone surfactant. Due to its strong surface tension reducing effect, VOK ®- UV3530 can improve the wettability of substrate. In the nonaqueous radiation curing system, it will be arranged at the film/air interface to improve leveling.

Recommended use

VOK ®- UV3530 is specially recommended for water-based radiation curing printing ink and varnish. It has limited applications in nonaqueous systems.

Recommended dosage

0.2-1% auxiliary dosage (purchase form) is based on the general formula.

The above recommended dosage is for reference, and the appropriate dosage shall be determined through a series of tests.

Adding method and processing guidance

It can be added at any stage, including after.
