Home > Products > 10. SF6, oil chemical test, dielectric loss series > New SF6 High-precision Gas Leak Detector DY-360
New SF6 High-precision Gas Leak Detector DY-360
- wuhan
- T/T Credit Card Cash Other
- 7 days
You May Like
Product Details
| Brand Name | Deya Power | Place of Origin | China | |
| Model Number | DY-360 |
Product Description
1、 Product characteristics
1. The internationally advanced pump suction, NDIR single beam dual wavelength infrared measurement technology is adopted, with high detection sensitivity, accuracy and stability;
2. High precision digital processing technology and unique drift control and temperature compensation circuit are adopted, with strong anti-interference capability;
3. It has full function self checking functions such as low battery, sensor failure and over range during detection;
4. Color large screen dot matrix LCD display and full Chinese menu function management are adopted;
5. The detection process displays the detection data in real time and has a dynamic waveform curve analysis chart;
6. The lower limit of the alarm can be set, and the screen displays the alarm set value, using the audible and visual alarm mode;
7. Automatic calculation of leakage amount and leakage rate of the tested equipment;
8. Self calibration function;
9. Large capacity rechargeable lithium battery, with continuous working time more than 5 hours;
10. Clock perpetual calendar function;
11. Small size, convenient for hand-held measurement;
12. It has 100 data and waveform storage functions, numbering and browsing query functions;
13. High brightness LED light source, which can be used for flashlight lighting;
2.2 Technical indicators
2、 Technical parameters
project | content | |||
1 | Product model | DY-360 SF6 Gas leak detector | ||
2 | Measurement method | NDIR Single beam dual wavelength infrared measurement technology | ||
3 | Monitoring gas | measuring range | Resolution | accuracy |
Sulfur hexafluoride gas | 0~2000ppm | 0.1ppm | ±(3%+5d) | |
4 | Repetitive performance | <2% | ||
5 | Air pump extraction speed | 0.4L/min | ||
6 | Duration | Not less than 5 hours | ||
7 | Instrument start-up warm-up time | ≤3minute | ||
8 | Corresponding time | Less than 30 seconds | ||
9 | recovery time | Less than 30 seconds | ||
10 | Charging adapter specifications | DC12V/2A | ||
11 | Surge (impact) immunity | ±1.2kV | ||
12 | ambient temperature | -20℃~+50℃ | ||
13 | ambient humidity | Relative humidity 5~95% (non condensing) | ||
14 | atmospheric pressure | 50kPa~110kPa | ||
15 | Degree of protection | IP33, Double insulation, CAT II standard | ||
16 | Overall dimensions | 200mm wide × 240 deep mm × 80mm high | ||
17 | Main engine weight | 1KG | ||
