JH25-110 C Frame Two Point Press Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
250ton C Frame Double Crank Automatic Power Press Machine JH25-250NegotiableMOQ: 1 -
RBM50HV Electrical Round Bending Machine With China Low PriceNegotiableMOQ: 1
-
Manual Press Machine HP10S 10 Ton Shop Press With Competitive PriceNegotiableMOQ: 1
-
Manual Shop Press Machine 20 Ton HP-20S for Press WorkNegotiableMOQ: 1
-
HP-30S 30 Ton Manual Oil Press Machine for Metal WorkNegotiableMOQ: 1
Product Description
Punching press machine Features:
1.Steel welded body, heat treatmen, high rigidity, accuracy and stability;
2.Double crank, high frequency quenching, grinding treatment;
3.Hex retangular guideway;
4.Wet clutch, hydraulic overload protector;
5.Auto lubrication, electric die adjustment.
1.Steel welded body, heat treatmen, high rigidity, accuracy and stability;
2.Double crank, high frequency quenching, grinding treatment;
3.Hex retangular guideway;
4.Wet clutch, hydraulic overload protector;
5.Auto lubrication, electric die adjustment.
Size Information
Specifications |
Unit |
JH25-110 |
JH25-160 |
||||||
Type |
S |
H |
S |
H |
|||||
Nominal Force |
KN |
1100 |
1600 |
||||||
Nominal Stroke |
mm |
5 |
6 |
||||||
Slide Stroke |
mm |
180 |
110 |
200 |
130 |
||||
Slide Strokes Per Minute |
Fixed |
min-1 |
50 |
70 |
45 |
60 |
|||
Variable |
35-60 |
40-70 |
35-55 |
40-70 |
|||||
Maximum Die Set Height |
mm |
400 |
435 |
450 |
485 |
||||
Die Height Adjustment |
mm |
90 |
100 |
||||||
Between slide center and frame |
mm |
350 |
390 |
||||||
Columns Distance |
mm |
1470 |
1600 |
||||||
Slide Bottom Size(LRxFB) |
mm |
1400x520 |
1500x580 |
||||||
Shank hole size |
mm |
3-Φ60x80 |
3-Φ60x85 |
||||||
Bolster Size(LRxFB) |
mm |
1880x680 |
2040x760 |
||||||
Bolster Thickness |
mm |
155 |
165 |
||||||
Bolster Surface Height |
kgs |
900 |
900 |
||||||
Motor Power |
KW |
11 |
18.5 |
||||||
Overall Dimension(LRxFB) |
mm |
1820x1970x3200 |
2080x2150x3380 |
||||||
Weight(Appriximate) |
Kg |
14000 |
19000 |
||||||
Press pressure |
Mpa |
0.55 |
0.55 |
0.55 |
0.55 |
||||
Machine Details
Standard accessories:
1) Wet clutch
2) Hydraulic overload protecting pump
3) Auto lubrication system
4) Manual lubrication system
5) Balance
sulinders for slide and upper die
sulinders for slide and upper die
6) Digital die height indicator
7) Joint for miss-feeding
8) Touch screen
9) Electronic crankshaft angle indicator
10) Cam controller
11) Rotary encoder
12) Movable operation panel
13) Die height adjusted motor
14) PLC:Programmable
logical controller
logical controller
15) Air source quick connector
16) Foundation bolts
17) Air blowing device
Optional accessories:
1) Light curtain
2) Foot pedal
3) Air cushion device
4) Die quick change device
5) Frequency changer
6) Automatic feeding the output
shaft
shaft
7) Shock Absorption Pads
8) Knock our device (Shank hole)
Machine Show:
