Vertical Drilling Machine Price for Metal Z5045-1 With CE
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Z5045-1 Auto Feed Vertical Drilling Machine With CENegotiableMOQ: 1 -
Mini Milling and Drilling Lathe Machine Model ZAY7045FG for Metal CuttingNegotiableMOQ: 1
-
High Precision ZAY7045FG Drilling and Milling Machine With CE StandardNegotiableMOQ: 1
-
ZAY7025G Gear-driven Bench Drilling Machine for Sale in ChinaNegotiableMOQ: 1
-
ZAY7030V Hot Sell Table Milling Machine Variable Speed Drilling and Milling Machine With CENegotiableMOQ: 1
We will reply you in 24 hours
Mordle: Z5040-1 benchtop
Item |
Z5045 |
Max.drilling capacity(iron/steel) |
45mm |
Spindle taper |
MT4 |
Worktable size |
380×380mm |
Spindle travel |
130mm |
Spindle nose to worktable |
700mm |
Spindle nose to base |
1125mm |
Column diameter |
98mm |
Spindle speeds range |
6steps:80~1500rmp |
Motor |
1.5kw |
N.W/G.W |
470/530KG |
Packing size(L×W×H) |
1850×950×1000mm |
Features:
1.Drilling, milling and tapping
2.Headstock and worktable up and down perpendicularly
3.Head swivels 360°horizontally
4.Gear driven, lower noise
5.Positive spindle lock
Standrad accessories:
1. Drill chuck 1-13mm/B16;
2. Draw bar;
3. Allen wrenchs;
4. Wedge;
5.Tie rod
Optional accessories:
1.Steel stand and chip tray ; 2. Halogen lamp;
3.Coolant system;
4. 58pcs clamping kits;
5. Face milling cutter diameter 63mm; 6.Milling chuck(8pcs/set);
7.DRO(2-axis or 3-axis)(for FG and FG-1 serials) ;
8.H/V precision rotary table HV-150mm
9.Table power feed X axis (Except for belt driven type);
10. Double speed motor
Located in Anhui Chizhou High-tech Development Zone, Chizhou WMT Group operates two companies. One is Chizhou WMT CNC Machinery Co. Ltd and the other is Chizhou WMT CNC Industrial Co., Ltd. The group deals in CNC machine, milling and drilling machine, drilling machine, lathe machine and all kinds of multi purpose machines.
