2108-1701031 42205 NJ205 Cylindrical Roller Bearings Size 25x52x15 for VAZ 1111 VAZ 2108 VAZ 2109 Gearbox Bearing
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Cylindrical Roller Bearing 92705 (25x55x18) Gearbox VAZ 2101 Intermediate Shaft (rear Support) 2101-1701073 / 6-92705NegotiableMOQ: 1 -
6-92705AE1 2101-1701073 Cylindrical Roller Bearings Size Cylindrical Roller Bearings for VAZ 2106 2107 GearboxNegotiableMOQ: 1
-
92705 Cylindrical Roller Bearing for Car VAZNegotiableMOQ: 1
-
Hot Sale Wear Resistance Single Column Centripetal Thrust Cylindrical Roller Bearings 42305 NJ305 Size 25x62x17mmNegotiableMOQ: 1
-
High Quality Cylindrical Roller Bearings Hot Sale 12507 NF2207 Size 35*72*23NegotiableMOQ: 1
Product Description
Title goes here.
Roller radial bearing with short cylindrical rollers 42205 has two flanges on the inner surface of the outer race and one on the outer surface of the inner race.
This design, in addition to the high carrying capacity, allows the product to work on the "stop" in one direction.Bearing GOST 42205 consists of a removable inner race and a block of rolling elements, which together with the outer ring forms a non-separable part. It has dimensions of 25x52x15 mm. The weight of the product, including packaging, does not exceed 0.14 kg.
Specification
GOST 520-2011: | 42205 |
ISO: | NJ205 |
Load-bearing: | Radial |
Outside diameter (D), mm: | 52 |
Inner diameter (d), mm: | 25 |
Overall width (B), mm: | 15 |
Inner ring outer diameter: | 35 |
Outer ring inner diameter: | 41.8 |
Weight, kg: | 0.142 |
Loading capacity, static H: | 2770 |
Loading capacity dynamic, H: | 29300 |
Rotational speed in the lubricant, rpm: | 13000 |
Rotational speed in oil, rpm: | 15000 |
Roller size, mm: | 6.5x6.5 |
Steel grade | GCR15 |
Application:
The bearing is widely used in domestic cars and trucks.
VAZ 1111 ("Oka"), VAZ 2108, VAZ 2109 - gearbox bearing (gearbox primary shaft), in models 2110, 2111, 2112 they are also placed on the front support of the box.
MAZ 537, 538 - bearing of the torque converter, engine, oil pump, models 543, 547, 7310, 7410 - the engine is installed.
KZKT tractors - a torque converter, an engine, an oil pump, an evacuation pump.
