Machinery Use 3617 22317 E CC CA MB W33 Double Row Spherical Roller Bearing Size 85x180x60 mm

22317 3617 spherical roller bearing description:

It is a double row spherical roller radial bearing. Of all bearing designs of the corresponding dimensions, this one has the highest load-carrying capacity. In bearings of this type, the rollers are located between an inner ring with two raceways and an outer ring with one spherical race. The most common modification is with a groove and holes in the outer ring for applying grease (3617 N).

Dimensions and characteristics of bearing 3617:

Inner diameter (d) - 85 mm.

Outside diameter (D) - 180 mm.

Width (height) (B) - 60 mm.

Outer cage width (C) - 60 mm.

Weight - 7.36 Kg

Dynamic load capacity (C) - 338.8 kN

Static lifting capacity (C0) - 440 kN

Limiting speed with grease - 1800 rpm

Limiting speed with liquid lubrication - 2400 rpm

Number of raceways - 2

Sealing - No

22317 3617 spherical roller bearing Anology:

W33 - Grease groove and lubrication holes;
CC, EC, CE4, CJ, E, EA, EX, E1 - steel cage, one piece or double;
M, MB, EG, CA - brass cage;
TVP, TNG - polyamide cage;
2CS, 2CS2 - seals (closed type).

3617 (with a brass cage), 53617 (with a steel cage), 153617, 13617, 113617 (under a cone), produced in accordance with GOST (520-89, new 520-11).

A: barreled package+outer carton+pallets
B: single box+outer carton+pallets
C: tube package+middle box+outer carton+pallets
D: According to your's requestion

Established in 2009,Shandong Vanlin bearing Co., Ltd is located in jinan western industrial area, jinancity, shandong province.
Our company is an enterprise integrating R&D, production, sales and service. The company specializes in the production of
industrial bearing, agriculture bearing, Automotive bearings, Petroleum Drilling Bearing and so on. We can provide hub units,
wheel bearing and kits, tensioner pulley, clutch assembly bearing, gearbox bearing and other bearings

Q: Are you trading company or manufacturer ?
A: We are factory and doing exporting by ourself.

Q:What’s your after-sales service and warranty?
A:1.12 months warranty or 30000km;
2. Replacements would be sent with goods of your next order;
3. Refund for defective products if customers require.

Q: Do you provide samples ? is it free or extra ?
A: Samples and trial order are both available, the sample can be free if it's not a big value, customer is supposed to take the
courier charge.

Q:Do you accept ODM&OEM orders?
A: Yes, we provide ODM&OEM services to worldwide customers, can also customize packaging box as per your requirements.
